Product Details
Description
N9K-C93360YC-FX2 Overview
Cisco Nexus 9300-FX2 series is an extension of Nexus 9300-FX series switches with higher bandwidth capacity. The switches offer a variety of interface options to transparently migrate existing data centers from 1-Gbps, and 10-Gbps speeds to 25- Gbps at the server, and from 10- and 40-Gbps speeds to 50- and 100- Gbps at the aggregation layer.
The platforms provide investment protection for customers, delivering large buffers, highly flexible Layer 2 and Layer 3 scalability, and performance to meet the changing needs of virtualized data centers and automated cloud environments.
Quick Specs
Table 1 shows the Quick Specs.
| Product Code | N9K-C93360YC-FX2 |
| Ports | 96 x 1/10/25-Gbps and 12 x 40/100-Gbps QSFP28 ports |
| Supported speeds | 1/10/25-Gbps on downlinks
40/100-Gbps on uplinks Breakout supported ports, 97-108: 4×10/25G |
| CPU | 4 cores |
| System memory | Upto 24 GB |
| SSD drive | 128 GB |
| System buffer | 40 MB |
