| Preview | 1/4/6/8/9 panes |
| Disks | 1 disk |
| Local decoding | 8MP (4K): 1-channel 30 fps; 4MP: 2-channel 30fps; 2MP (1080p): 4-channel 30 fps The decoding performance deteriorates by 50% when the NVR800 works with HOLOWITS Cameras to enable the AI function. |
| Playback/Download | 8 channel, 64 Mbit/s playback |
| Video forwarding | 64 Mbit/s playback |
| Recording mode | Manual recording, scheduled recording, motion detection-triggered recording, and recording triggered by I/O alarms. |
| Behavior analysis | Works with SDCs to implement intelligent capabilities, including motion detection, intrusion detection, tripwire crossing detection, audio abnormality detection, lens blocking detection, area entry/exit detection, fast movement detection, loitering detection, two-way head counting, queue length detection, head counting in an area, and mask detection. |
| Video input | 8 channels, 80 Mbit/s access |
| Recording playback | 8-channel simultaneous playback Simultaneous playback Controls: fast forward (2x, 4x, 8x, or 16x) and slow-down (1/16x, 1/8x, 1/4x, or 1/2x) |
| Video input | 8 channels, 80 Mbit/s access |
| Video forwarding | 64 Mbit/s |
| Playback/Download | 64 Mbit/s playback |
| HDMI | One HDMI 1.4 port; resolutions: 1024 x 768, 1280×720, 1280×1024, 1440 x 900, 1920 x 1080, 2560 x 1440, 3840×2160 |
| VGA | One VGA port; resolutions: 1024 x 768, 1280 x 720, 1280×1024,1440 x 900, 1920 x 1080 |
| Local decoding | 8MP (4K): 1-channel 30 fps; 4MP: 2-channel 30fps; 2MP (1080p): 4-channel 30 fps The decoding performance deteriorates by 50% when the NVR800 works with HOLOWITS Cameras to enable the AI function |
| Memory | 4 GB DDR3 |
| CPU | 32-bit multi-core high-performance processor |
| Disk port | SATA2.0 |
| Disk type | 4TB/6TB/8TB per port |
| Recording mode | Manual recording, scheduled recording, motion detection-triggered recording, and recording triggered by I/O alarms. |
| Recording playback | 8-channel simultaneous playback Simultaneous playback Controls: fast forward (2x, 4x, 8x, or 16x) and slow-down (1/16x, 1/8x, 1/4x, or 1/2x) |
| Search mode | By time, recording type, or AI event |
| Download mode | In batches or by segment |
| Network protocol | TCP, UDP, RTP, RTSP, HTTP, DNS, NTP, SMTP, and DHCP |
| Web access | Compatible with Internet Explorer 9, 10, and 11 |
| P2P CLOUD service | Access to CLOUD services and remote access through mobile apps |
| Device access | HOLOWITS SDK and ONVIF |
| Audio format | G.711a/G.711u |
| Video format | H.264/H.265 |
| Behavior analysis | Works with SDCs to implement intelligent capabilities, including motion detection, intrusion detection, tripwire crossing detection, audio abnormality detection, lens blocking detection, area entry/exit detection, fast movement detection, loitering detection, two-way head counting, queue length detection, head counting in an area, and mask detection. |
| Target reference libraries | 16 |
| Total target library capacity | 10000 |
| Structured data storage | Structured vehicle data storage |
| Log type | Log functions: operation logs, systemlogs, alarmlogs, parametermodification logs, recording logs, intelligent logcheck, andlogstorage |
| Management mode | Web and LDU |
| Audio output | 1 channel, RCA port |
| USB port | 2 x USB 2.0 port (1 port on the front panel and 1 port on the rear panel) |
| Network port | 1 x 10/100/1000 Mbit/s Ethernet port |
| Operating temperature | 0°C to 45°C |
| Operating humidity | 20% to 90% |
| Power consumption | ≤ 3 W (excluding hard disk and PoE output) |
| Weight | Net Weight 1 kg (excluding hard disks) Gross Weight 1.4kg (excluding hard disks) |
| Shelf | 1 U |
| Dimensions | Equipment dimensions 54 mm (H) x 300 mm(W) x 227mm(D) Package dimensions 100 mm (H) x 425 mm(W) x 270mm(D) |
| Power supply | 12 V/2 A |
| Certification | CE, RoHS, WEEE, CCC and CQC |
