| Computing power | 1 TOPS |
| Memory | DDR3 1.0 GB |
| Flash type | SPI NAND FLASH 512.0 MB |
| Focal length | 2.7-12mm |
| Max Aperture | F1.3(W)-F2.4(T) |
| Image sensor | 1/2.7″ CMOS/5MP 2880(H)*1620(V) |
| Lens aperture type | Fixed iris |
| Angle of view | Horizontal:32°(T) to 95°(W);Vertical:18°(T) to 52°(W) |
| IR range | 50m |
| Zoom | Digital zoom:16x; Optical zoom: 4x |
| IR Wavelength | 850 nm |
| Target | Target detectio/Target attribute recognition |
| Target recognition | Supported |
| Person | Person detection |
| Behavior analysis | Fast movement/Tripwire crossing/Intrusion/Area entry or exit/Loitering |
| Crowd flow analysis | Queue length/Head counting/Crowd flow statistics |
| Defocus | Supported |
| Alarm information | HTTPS certificate expiration/SDK certificate expiration/App verification certificate expiration/Level-2 app verification certificate expiration/Mobile app certificate expiration/SDK root certificate expiration/SDK revocation certificate expiration/GB 35114 certificate expiration/802.1X certificate expiration/Log certificate expiration/Network disconnection/Network packet receiving anomaly/Full hard disk/Hard disk removal/Failure to write data to disks/Media stream interrupted/Log saving anomaly /Flash read/write/Temperature sensor fault/Hot swapping of network adapters/Video loss/Lens PT optocoupler fault/PTZ configuration anomaly |
| Open OS | Supported |
| Data openness | SDK (proprietary protocol)/REST API (proprietary protocol)/GA/T 1400/GB/T 28181 (2011, 2016) /ONVIF Profile S/G/T/M |
| Video frame rate | 5-megapixel: 20 fps; < 5-megapixel: 30 fps or 25 fps |
| Scene adaptation | Backlight adaptation/Overcast adaptation |
| Day/Night mode | Day/Night mode: automatic, color, B/W, and scheduled (default: automatic) Trigger mode: image triggered or internal signal triggered (default: image triggered) |
| WDR | 120db |
| White balance | Auto/Manual/OnePush |
| HLC/BLC | Supported/Supported |
| Shutter speed | Shutter speed: 1/100000s to 1/25s Default shutter speed in live video mode: 1/25s (shutter limit: 1/25s) Default shutter speed in target checkpoint mode: 1/25s (shutter limit: 1/25s) Default shutter speed in micro checkpoint mode: 1/25s (shutter limit: 1/250s) Default shutter speed in behavior analysis mode: 1/25s (shutter limit: 1/25s) |
| SNR | >45dB |
| Primary stream resolution | 2880X1620(5MP),2560×1440(4MP),2304×1296(3MP),1920×1080 (1080P),1280×720(720P),720×576(PAL) |
| Secondary stream resolution | Secondary stream 1:720×576(PAL),720×480(NTSC),352×288(PAL), 352×240(NTSC); Secondary stream 2:352×288(PAL),352×240(NTSC) |
| Video bit rate | 1080p to 4K: 512 kbit/s to 16 Mbit/s 1080p: 256 kbit/s to 16 Mbit/s 720p: 256 kbit/s to 8 Mbit/s D1: 256 kbit/s to 4 Mbit/s CIF: 32 kbit/sto 1 Mbit/s |
| Digital noise reduction | 2D/3D noise reduction |
| Audio encoding format | G.711a/G.711u/G.726/OPUS/AAC |
| Audio sampling rate | G.711a/G.711u/G.726:8K OPUS:8K/12K/16K/24K/48K AAC:8K/16K/22. 05K/24K/32K/44.1K/48K |
| Audio bit rate | G.711a/G.711u: 64 kbit/s G.726: configurable (16/24/32/40 kbit/s) OPUS: configurable (16/24/32/40/64/96/128/160/192/224/256/288 kbit/s) AAC: 8 kHz sampling rate: 16/22/24/32/48 kbit/s 16 kHz sampling rate: 24/32/48/64/96 kbit/s 22.05/24/32 kHz samplingrate: 32/48/64/96/128 kbit/s 44.1/48 kHz sampling rate: 48/64/96/128/256 kbit/s |
| Protocols supported by IPv4 | TCP, UDP, IPv4, DHCP, DNS, ICMP, IGMP, HTTPS, FTP, SFTP, RTP, RTSP, RTCP, SIP, ARP, SSL, NTP, SNMP (V1/V2/V3), 802.1X, QoS,SMTP, and PPPoE. Note: The northbound protocol needs to adapt to the PPPoE dialup scenario. |
| Protocols supported by IPv6 | HTTPS,RTP,RTCP,RTSP,Onvif,IPv6,ICMPv6,DHCPv6 |
| Web Browser | 32- or 64-bit Windows 7, Windows 8, or Windows 10 Google Chrome: 32-bit Google Chrome 38–49 (The IE Tab plug-in must be installed for Google Chrome 46–49.) Versions later than 10.0.0.SPC300: 32- or 64-bit Google Chrome 50+ Internet Explorer: 32-bit Internet Explorer 10 and 11 Firefox: 32-bit Firefox 35–51 Versions later than 10.0.0.SPC300: 32- or 64-bit Firefox 70+ Microsoft Edge: Versions later than 10.0.0.SPC300: 32- or 64-bit Microsoft Edge 50+ Restrictions: Compatibility problems may occur on the Firefox browser. (Pages may be out of order for a short time.) |
| Media security | Supports web- or SDK-based media stream encryption; supports a maximum of two channels of encrypted media streams; media stream encryption and full intelligence, target recognition, or image upload through SFTP/FTP cannot be enabled at the same time; after the intelligent analysis function is enabled, only one-channel stream encryption is supported; supports encrypted storage of data in SD cards. By default, RTSP uses MD5 digest authentication. |
| Video digital watermark | Supported |
| Image digital watermark | Supported |
| User rights | Three user roles: administrator, advanced operator, and common operator |
| Security mode | User name and password authentication, 802.1X authentication, and HTTPS digital certificate |
| Secure boot | Supported |
| System intrusion detection | Promiscuous network adapter detection;Sensitive system file detection;Unauthorized super account detection;Botnet detection; Rootkit detection;Trustlisted program detection ;Privilege escalation detection |
| Storage port | One microSD card slot that supports microSDHC/microSDXC (maximum memory card capacity: 256 GB) |
| Alarm port | 2 input port and 1 output port |
| Network port | One RJ45 10M/100M adaptive Ethernet port |
| Communication serial port | RS-485 port |
| Audio port | Supported (one-channel LINE IN or one-channel external microphone)/Supported (one- channel LINE OUT) |
| Power type | DC12V,PoE(IEEE 802.3af) |
| Power consumption | Maximum:12.2W,typical:3.2W |
| Operating temperature | -30℃ to 60℃ |
| Storage temperature | -40℃ to 70℃ |
| Operating humidity | 5% to 95%(non-condensing) |
| Surge protection | 4kV |
| IP rating | IP67 |
| Equipment Anti Corrosion | Class C |
| Weight | Net weight 1.0kg;Gross weight 1.2kg |
| Dimensions | Device dimensions 330.4mm×108.6mm×92mm;Package dimensions 376mm×139mm×182mm |
| Language | Simplified Chinese, English, French, Spanish, Portuguese (Europe), Portuguese (Brazil), Thai, Italian, and Turkish |
