| Focal length |
5-75mm |
| Max Aperture |
F1.6(W) to F2.8(T) |
| Image sensor |
1/2.8” CMOS |
| Lens aperture type |
Auto DC-IRIS |
| Angle of view |
Horizontal:54° to 4° |
| Angle of view |
Vertical: 32° to 2.3° |
| Angle of view |
Diagonal: 64.5° to 4.6° |
| IR range |
150m |
| PTZ rotation angle |
Pan Range: 360° |
| PTZ rotation angle |
Tilt Range: -5° to 90° |
| Pan speed |
Configurable, from 0.1~80°/s; Preset speed: 80°/s |
| Tilt speed |
Configurable, from 0.1°~ 80°/s, Preset speed: 80°/s |
| Park action |
Support |
| Tour |
Support |
| Preset position |
360 |
| Home position |
One home position |
| Video encoding format |
Smart H.265/H.264/MJPEG |
| Video encoding channels |
Triple streams |
| Video frame rate |
Main stream: |
| Video frame rate |
1920×1080,1280×960,1280×720 25/30fps |
| Video frame rate |
Sub stream: |
| Video frame rate |
25fps (704 × 576, 640 × 480, 352 × 288) |
| Video frame rate |
30fps (704 × 480, 640 × 480, 352 × 240) |
| Video frame rate |
Third Stream: |
| Video frame rate |
25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) |
| Video frame rate |
30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
| Min illumination |
Color：0.005Lux @ (F1.6，AGC ON)；B/W：0.001Lux @(F1.6，AGC ON);0Lux with IR |
| Day/Night mode |
IR Cut filter |
| WDR |
120 dB |
| White balance |
Auto/Manual/Indoor/Outdoor |
| Highlight compensation |
Support |
| Digital noise reduction |
Auto/Manual |
| Defogging |
Electronical |
| EIS |
Support |
| Power type |
DC12V or PoE+ (802.3.at) |
