The Cisco IE-4010-4S24P is a rugged 1RU industrial Ethernet switch for deployments that require a large number of copper PoE endpoints plus fibre connectivity. It is commonly considered for industrial CCTV, wireless, transport, utilities, manufacturing and harsh-site access networks.

IE-4010-4S24P port configuration

Best-fit applications

• Industrial IP cameras and video-surveillance networks
• Warehouse and outdoor wireless access points
• Manufacturing cells and process-control networks
• Roadside, rail and transport communications
• Utility and energy sites requiring ruggedized access switching

PoE design guidance

The 24 copper ports make this model suitable for powered endpoints, but the usable PoE budget depends on the selected power supplies and redundancy design. Build a device-level power schedule covering normal draw, maximum draw and startup surge. Reserve headroom for future cameras or access points rather than sizing only for the initial load.

Fibre and SFP compatibility

The four SFP interfaces can connect the access layer to aggregation switches or remote cabinets. Confirm the transceiver speed, wavelength, single-mode or multimode fibre, connector type and required distance. Industrial-temperature optics may be required where ambient conditions exceed ordinary data-centre limits.

Software, routing and security

Verify the installed IOS release, licence entitlement and feature requirements before ordering. Layer 2 segmentation, authentication and secure management are common requirements. Projects needing dynamic routing or advanced multicast should validate the applicable software licence and supported feature set.

Power-supply and BOM checklist

• IE-4010-4S24P switch with verified condition and serial details
• Correct primary and optional redundant power supplies
• SFP modules matched to every fibre link
• Rack mounting and grounding accessories
• PoE endpoint power schedule
• Software licence and support entitlement
• Spare optics, power supply or switch where downtime is critical

IE-4010-4S24P versus IE-4010-16S12P

Choose the 4S24P when the design is copper and PoE heavy. Choose the 16S12P when fibre density is more important and twelve powered copper ports are sufficient. Both belong to the same IE 4010 family, but they serve different cabling architectures.

Lifecycle and replacement planning

Before using the IE-4010-4S24P for a new rollout, compare its lifecycle, software support and feature roadmap with current Cisco industrial platforms. For an installed base, document spares, configuration backups, optics and power supplies so a failure does not create an extended outage.

See the complete Cisco IE 4010 buying guide or compare lower-density models in our industrial-switch comparison.

Frequently asked questions

How many PoE ports does the IE-4010-4S24P provide?

It provides 24 copper Gigabit Ethernet ports designed for PoE/PoE+ endpoints, subject to the available system power budget.

How many fibre ports are included?

The model provides four Gigabit SFP interfaces. The required SFP modules normally need to be specified separately.

Is it suitable for outdoor CCTV?

It can support outdoor-camera networks when installed in a correctly rated enclosure with suitable power, grounding, surge protection, fibre and environmental design.

What should buyers verify on refurbished equipment?

Verify serial numbers, hardware condition, fans and power supplies, licence status, software version, port tests, included accessories and warranty terms.

Request a compatible quotation: Send Gear Net Technologies your endpoint count, PoE load, fibre distances, routing needs and site temperature range.
