| Pixel Pitch (mm) (Horizontal/Vertical) |
P3.91/P3.91 |
| Pixel Density (dot/m²) |
65536 |
| Transparency Rate |
80% |
| Display Dimension (mm)(w*h) |
1000×2000 |
| Profile Dimension (mm)(w*h) |
1021x2230x75; 1021×2452×500 |
| Resolution (dot) (w*h) |
256×512 |
| Brightness (cd/m²) |
≥3000 |
| Weight (Kg/set) |
40 |
| Encapsulation Type |
Light Board &Driving Board Integrated |
| Scanning Mode |
Static Driving (Single Pixel Single Control) |
| Lifespan |
≥100,000.00 hours |
| Pixel Configuration |
16bit |
| Maximum Power Consumption(w/m²) |
1000 |
| Average Power Consumption(w/m²) |
375 |
| Control System |
Colorlight /Novastar |
| Input Voltage |
AC100~240V 50/60 Hz |
| Working Voltage for Module |
DC4.2V±0.2V |
| Working Temperature |
Temperature -20°℃~50℃ |
| Working Humidity |
Humidity:20%-85% (Without Condensation) |
| Storage Temperature |
Temperature -20℃~60℃ |
| Storage Humidity |
Humidity:10%-85% (Without Condensation) |
| Protection Degree |
IP20 |
| Frame Material |
Aviation Aluminum Alloy |
| Installation Environment |
Indoor |
| Packing Way |
Pearl Cotton+Wooden case/Airbox |
