| OS System |
Embedded Linux |
| Analog Video Input |
8 BNC port |
| Input platform |
TVI/AHD/CVI: 1080P/1080P Lite/720P/720P Lite/WD1 |
| IP Video input |
4 channels, 32Mbps |
| Total Input |
12 channels |
| Playback |
8 channels 60Mbps |
| Local decoding |
8 channels Analog cameras, 4 channels 5MP@25fps |
| HDMI |
One HDMI port, resolution: 1920 × 1080 / 1280 × 1024 / 1024 × 768 |
| VGA |
One VGA port; resolutions: 1920 × 1080 / 1280 × 1024 / 1024 × 768 |
| BNC |
CVBS (used as the main or spot output) |
| Preview |
1/4/6/8/9/13/16 panes |
| Disks |
1 |
| Disk port |
SATA 2.0 |
| Disk type |
Up to 10TB |
| Resolution |
5MP Lite/4MP Lite / 1080P/1080P Lite/720P/WD1/D1 |
| Frame Rate (Analog Channel) |
5MP Lite@10fps (PAL/NTSC), 4MP Lite/1080P@12fps (PAL)/15fps (NTSC), 1080P Lite/720P/WD1/D1@25fps (PAL)/30fps (NTSC) |
| Frame Rate (IP Channel) |
25fps (PAL)/30fps (NTSC) |
| Bit Rate |
32Kbps ~ 4Mbps |
| Search |
Time slice/time/event/tag search |
| Smart Search |
Highlight colors to display the camera record in a certain period of time, different colors refer to different record events |
| Video format |
H.264/H.265 |
| Audio format |
G.711a/G.711u |
| Network protocols |
TCP/IP, PPPoE, DHCP, DNS, DDNS, UPnP, HTTP, HTTPs, NTP, SMTP |
| Device access |
BNC and ONVIF |
| Client access |
MAX 5 users |
| Management mode |
LDU |
| Functions |
Play, pause, FF, FB, digital zoom, etc. |
| Network port |
One RJ45 100Mbps |
| USB port |
2 x USB 2.0 ports |
| Audio input |
4 channels, RCA port |
| Audio output |
1 channel, RCA port (linear, 600Ω) |
| Operating temperature |
-10°C to 50°C |
| Operating humidity |
10% to 90% |
| Power consumption |
≤ 10 W (excluding hard disk and PoE output) |
| Power supply |
12 V/2 A |
| Dimensions |
45mm (H) x 300mm (W) x 249mm (D) |
| Shelf |
1 U |
| Certification |
CE |
