| OS System |
Embedded Linux |
| Analog Video Input |
8 channels IP camera |
| Resolution |
6MP/5MP/4MP/3MP/1080P/960P/720P/D1/CIF |
| IP Video input |
8 channels, 64Mbps |
| Playback |
8 channels 60Mbps |
| Local decoding |
8 channels 6MP@25fps |
| Decoding Capability |
1CH 6MP; 4CH 1080P |
| HDMI |
One HDMI port, resolution: 1920 × 1080 / 1280 × 1024 / 1024 × 768 |
| VGA |
One VGA port; resolutions: 1920 × 1080 / 1280 × 1024 / 1024 × 768 |
| Preview |
1/4/6/8/9 panes |
| Disks |
1 |
| Functions |
Play, pause, FF, FB, digital zoom, etc. |
| Disk port |
SATA 3.0 |
| Disk type |
Up to 10TB |
| Resolution |
6MP/5MP/4MP/3MP/1080P/960P/720P/D1/CIF |
| Frame Rate |
30fps/25fps(NTSC/PAL) |
| Search |
Time slice / time / event / tag search |
| Smart Search |
Highlight colors to display the camera record in a certain period of time, different colors refer to different record events |
| Video format |
H.265+ /H.265 /H.264 |
| Audio format |
G.711a/G.711u |
| Network protocols |
TCP / IP, IPv4, IPv6, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, RTSP, ONVIF, etc. |
| Device access |
SDK and ONVIF |
| Client access |
MAX 10 users |
| Management mode |
LDU |
| LPR function |
support |
| Alarm Type |
Manual, sensor, motion, exception, smart events, etc. |
| Alarm Triggering |
Record, snapshot, buzzer, preset, e-mail, etc. |
| Network port |
One RJ45 100Mbps |
| USB port |
2 x USB 2.0 port (one on the front panel and one on the rear panel) |
| Operating temperature |
-10°C to 50°C |
| Operating humidity |
10% to 90% |
| Power consumption |
≤ 5 W (excluding hard disk and PoE output) |
| Power supply |
12 V/1.5 A |
| Dimensions |
42 mm (H) x 255 mm (W) x 222 mm (D) |
| Shelf |
1 U |
| Certification |
CE |
