| Output |
4ch HDMI output |
| Ethernet |
100M/1000M self adaptive |
| Audio input |
2ch，by Ф3.5 audio interface |
| Audio output |
2ch，by Ф3.5 audio interface |
| Alarm output |
support network alarm input |
| USB2.0 |
support |
| RS232/422/485 |
support |
| Network video decoding |
H.265,H.264 |
| Network video input |
4K, 1080P,1080I,720P,D1 |
| HDMI ouput resolution |
1024×768P@60hz,1280×720P@60hz,1366×768P@60hz, 1920×1080P@60hz,3840×2160@60hz |
| Video decode and display |
4ch 4K or 32ch 1080P or 64ch 720P or 128ch D1 |
| Monitor splicing |
4 monitor to splice and display one video |
| Split |
maximum 64 split,1/4/6/8/9/10/16/25/36/64 splitting mode and display，or split by user-define. |
| OSD |
Window, Channel,label, alarm, etc. information |
| Audio Codec |
G.711,G.726,ADPCM encode/decode |
| On/Mute |
Supports all channels and single channel set individually |
| Audio input |
2ch audio encode, it can open/close audio input. |
| Power supply |
AC100 to 230 |
