| Image sensor | 1/2.7″ CMOS/5MP 2560(H)*1920(V) |
| Min illumination | Color: 0.005 lux (F1.6, AGC ON); B/W: 0.0025 lux (F1.6, AGC ON) or 0 lux (infrared illuminator enabled) |
| Day/Night mode | Supported; automatic (ICR)/Color/B/W (default: automatic) Sensitivity level: high (default), medium, and low Image triggering /Internal triggering |
| White balance | Auto/Manual/OnePush |
| Digital noise reduction | 2D/3D noise reduction |
| WDR | 120 dB |
| HLC/BLC | Supported/Supported |
| EIS | Not supported; Sensitivity levels are not supported. |
| Optical Defogging/Algorithm-assisted Defogging | Not Supported/Supported |
| Signal-to-Noise Ratio(SNR) | > 45 dB |
| Power type | 12 V DC and PoE (IEEE 802.3af) |
| Power consumption | Maximum: 6 W; typical: 3.3 W |
| Operating temperature – | –30°C to +60°C |
| Operating humidity | 5% to 95% (non-condensing) |
| Surge protection | 4 kV |
| IP rating | IP67 |
| Equipment Anti Corrosion | Class C corrosion resistance |
| IK rating | IK10 |
| Weight | Net weight 0.8 kg;Gross weight 1kg |
| Dimensions | Device dimensions φ127 mm x 97 mm; Package dimensions 112 mm x 147 mm x 147 mm |
