Huawei OptiX OSN 1800 II Enhanced


< tbody >

Model: Huawei OptiX OSN 1800 II Enhanced – Huawei OptiX OSN 1800
Detail: Huawei OptiX OSN 1800 II Enhanced chassis, supports full-granularity cross-connections and multiplexing, a maximum of 200 Gbit/s OTN capacity, 160Gbit/s packet capacity, 50 Gbit/s SDH higher-order and 20 Gbit/s SDH lower-order capacities, and supports ODUk (k = 0, 1, 2, 2e, C2, flex)

Share this product


Huawei OptiX OSN 1800 I Enhanced Specification

Dimensions (mm) 88 x 442 x 220 (H x W x D) (excluding mounting ears)
Number of service board slots 6
Optical-layer cross-connect capability 1-degree to 9-degree ROADM
Device capacity OTN • 160 Gbit/s OTN capacity (OTN+PKT+SDH)

• 200 Gbit/s OTN capacity (OTN+SDH)

Packet • Packet switching capacity: 160 Gbit/s (128 bytes)

• Packet processing capability: 150 Mpps (64 bytes)

TDM 50 Gbit/s higher-order capacity, 20 Gbit/s lower-order capacity
Maximum number of wavelengths DWDM 80
Maximum rate per channel 200 Gbit/s
Supported service type SDH service (STM-1/4/16/64), PDH service (E1/T1/E3/T3/E4)

OTN service (OTU1/2/2e/4), Ethernet service (FE/GE/10GE/40GE/100GE)

CPRI service, OBSAI service, PCM service

SAN service, video, and others

PCM interface FXS/FXO, 2/4 line audio+E&M, G.703 64 kbit/scodirectional,V.35/V.24(synchronous/asynchronous RS232)/X.21,RS449(RS423A/RS422A)/RS530/RS530A/RS485/Dry Contact
Network application Pure packet networking, pure OTN networking, and pure TDM networking

MS-OTN networking (OTN+packet+TDM) and OTN+TDM networking


and protection

Network-level protection (OTN) Client 1+1 protection, intra-board 1+1 protection, ODUk SNCP, optical line protection, tributary SNCP, and LPT
Network-level protection (packet) Tunnel APS, PW APS/FPS, LPT, LAG, ERPS, LMSP, packet SNCP, and MRPS
Network-level protection (TDM) • SDH protection: SNCP, linear MSP, TPS, and ring MSP

• EoS protection: LAG, DLAG, LCAS, LPT, and STP/RSTP

• PCM protection: E1 SNCP, 64K SNCP, and hitless protection switching



• Backup of cross-connect, system control, and clock units

• Power supply backup

• Fan backup

Easy O&M OD and FD systems
Synchronization • Physical-layer clock (OTN&packet&SDH)

• IEEE 1588v2 (OTN&packet)

• ITU-T G.8275.1/G.8273.2 (OTN&packet)

Power supply • DC power input Standard operating voltage: –48 V DC/–60 V DC
