HPE Server Controller 843199-B21
No customer reviews yet
| Model: | 843199-B21 |
| Detail: | HPE Smart Array P840ar internal SAS controller with 2GB FBWC, 12Gb/s SAS and two internal x8 ports. |
GNTME · PRODUCT ENQUIRY
Get a quote for your project
Send your quantity, delivery destination and required configuration. Ask us to confirm availability, condition and warranty in your quotation.
Buying several items? Include your model list in the enquiry.
- Description
- Reviews (0)
Description
HPE Smart Array P840ar Controller Overview
The HPE 843199-B21 is a Smart Array P840ar/2GB FBWC 12Gb 2-port Internal SAS Controller for HPE server storage configurations. It is intended for businesses, system integrators and procurement teams that need an internal controller with SAS and SATA drive support.
The controller provides 2 GiB of flash-backed write cache (FBWC), which is cache protected by flash-based technology. It has 16 SAS/SATA physical links across two internal x8 ports and supports 12Gb/s SAS and 6Gb/s SATA technology.
843199-B21 supports mix-and-match SAS and SATA drives on the same controller. It supports RAID and HBA mode, along with legacy and UEFI boot operation. RAID options listed for this controller are RAID 0, 1, 10, 5, 50, 6, 60 and 10 ADM.
The HPE Smart Array P840ar controller includes HPE SmartCache. HPE Secure Encryption is supported with an optional license. The unit also supports HPE SSD Smart Path, rapid parity initialization, rapid rebuild, drive erase, power efficiency features and recovery ROM protection against controller ROM corruption.
Specifications
| Specification | Detail |
|---|---|
| Model | HPE Smart Array P840ar/2GB FBWC 12Gb 2-port Internal SAS Controller |
| Part number | 843199-B21 |
| Storage interface | SAS/SATA |
| Internal connectivity | 16 physical links across two x8 internal ports |
| SAS speed | 12Gb/s SAS, with 1200 MB/s theoretical bandwidth per physical lane |
| SATA speed | 6Gb/s SATA, with 600 MB/s theoretical bandwidth per physical lane |
| Cache | 2 GiB flash-backed write cache |
| Host interface | PCI Express Gen3 x8 link |
| Drive support | Up to 200 physical drives and up to 64 logical drives |
| Form factor | Full-height, half-length low-profile PCI Express |
| Dimensions excluding bracket | 16.8 cm x 11.1 cm x 1.5 cm |
| Included item | HPE Smart Storage 96W Battery |
Applications / Who It Is For
843199-B21 is relevant where an internal SAS/SATA controller is required for a server storage configuration with protected write cache and multiple RAID options.
- Server deployments using SAS or SATA storage drives.
- Configurations requiring two internal x8 ports and 16 physical SAS/SATA links.
- Storage designs using RAID or HBA mode.
- Systems using legacy or UEFI boot operation.
- Procurement requests that require the exact HPE part number 843199-B21.
FAQ
What controller is 843199-B21?
843199-B21 is the HPE Smart Array P840ar/2GB FBWC 12Gb 2-port Internal SAS Controller.
Does this controller support SATA drives?
Yes. It supports 6Gb/s SATA technology and can use SAS and SATA drives on the same controller.
Frequently asked questions
What is HPE 843199-B21?
HPE 843199-B21 is the HPE Smart Array P840ar/2GB FBWC 12Gb 2-port Internal SAS Controller.
What storage interfaces does 843199-B21 support?
It supports SAS and SATA storage interfaces, including 12Gb/s SAS and 6Gb/s SATA technology.
What cache does the controller include?
The controller includes 2 GiB of flash-backed write cache and an HPE Smart Storage 96W Battery.
How many drives can the controller support?
The controller supports up to 200 physical drives and up to 64 logical drives.
Official manufacturer information: Hpe datasheet
