| Analog Video Input |
8 BNC port |
| Input Resolution |
TVI/AHD/CVI: 5MN@12fps/4MN@15fps/1080P@30fps |
| IP Video input |
8 channels, 80Mbps |
| Total Input |
8 Channels (IP mode), 8 Channels (Coaxial mode or Hybrid mode) |
| Playback |
8CH (5MP-N coaxial input), 8CH (Coaxial or Hybrid mode), 8CH IP mode |
| Local decoding |
4*5MN@5fps/8*D1@12fps |
| Resolution |
5MN/4MN/1080P/1080N |
| Frame Rate |
Analog Channel: 5MN@5fps/4MN@7fps/1080P@7fps/1080N@14fps, IP Channel: 5MP@25fps |
| Bit Rate |
128Kbps ~ 12288Kbps |
| Search |
Time Slice / Time / Event / Tag Search |
| Smart Search |
Highlight colors to display the camera record in a certain period of time, different colors refer to different record events |
| Operating temperature |
-10°C to 55°C |
| Operating humidity |
10% to 90% |
| Power consumption |
≤ 10W (excluding hard disk) |
| Power supply |
12 V/2 A |
| Dimensions |
44mm (H) x 215mm (W) x 255mm (L) |
| Size |
280mm*260mm*50mm (L*W*H) |
| Weight |
699g |
