| Environmental Parameters |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 131 °F |
| Humidity Range Operating | 10 – 90% (non-condensing) |
| Header |
| Compatibility | PC |
| Manufacturer | Hewlett-Packard |
| Packaged Quantity | 1 |
| Product Line | HPE FlexFabric |
| Model | 556FLR-SFP+ |
| Brand | HPE |
| Miscellaneous |
| Compliant Standards | ACA, ACPI 1.1, BSMI Class A, CISPR 22 Class A, EN 60950, EN55022 Class A, EN55024, FCC Class A certified, ICES-003 Class A, MIC Class A, RoHS 6/6, UL, VCCI Class A ITE |
| Networking |
| Type | Network adapter |
| Connectivity Technology | Wired |
| Data Transfer Rate | 10 Gbps |
| Data Link Protocol | 10 Gigabit Ethernet |
| Compliant Standards | IEEE 802.1p, IEEE 802.1Q, IEEE 802.1Qau, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ap, IEEE 802.3az, IEEE 802.3x |
| Features | Auto-negotiation, Jumbo Frames support, Large Send Offload (LSO), PXE support, Receive Side Scaling (RSS), Wake on LAN (WOL) |
| Interface Type | PCI Express 3.0 x8 |
| PCI Specification Revision | PCIe 3.0 |
| Processor |
| Installed Qty | 1 |
| Manufacturer | Emulex |
| RAM |
| Installed Size | 128 MB |
| System Requirements |
| Min Operating System | Microsoft Windows HPC Server 2008, Microsoft Windows Server 2008, Microsoft Windows Server 2008 R2, Red Hat Enterprise Linux 5.x, Red Hat Enterprise Linux 6, SunSoft Solaris 10, SuSE Linux Enterprise Server 10, SuSE Linux Enterprise Server 11, VMware ESX 4.0, VMware ESX 4.1 |
