| Environmental Parameters |
| Min Operating Temperature |
41 °F |
| Max Operating Temperature |
131 °F |
| Humidity Range Operating |
10 – 90% (non-condensing) |
| Header |
| Compatibility |
PC |
| Manufacturer |
Hewlett-Packard |
| Packaged Quantity |
1 |
| Product Line |
HPE |
| Model |
570M |
| Brand |
HPE |
| Miscellaneous |
| Compliant Standards |
ACA, AS/NZS 3548, CAN/CSA C22.2 No. 60950, CISPR 22, EMC, EN 60950, EN55022, EN55024, FCC CFR47 Part 15, FCC Class A certified, ICES-003, IEC 60950, MIC, RoHS 6/6, RRL, UL, UL 60950, VCCI |
| Networking |
| Type |
Network adapter |
| Connectivity Technology |
Wired |
| Data Transfer Rate |
10 Gbps |
| Data Link Protocol |
10 Gigabit Ethernet |
| Compliant Standards |
IEEE 802.1as, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3p, IEEE 802.3x |
| Features |
Checksum offload support, Extended Message-Signaled Interrupts (MSI-X), IPv6 support, Jumbo Frames support, Large Send Offload (LSO), PXE support, Quality of Service (QoS), Receive Side Scaling (RSS), Single Root I/O Virtualization (SR-IOV), TCP Segmentation Offload (TSO), Temperature sensor, Virtual Machine Device Queues (VMDq), Virtualization Technology for Connectivity (VT-c) |
| Interface Type |
PCI Express 2.0 x8 |
| Network Transport Protocol |
TCP/IP, UDP/IP |
| Ports |
| Qty |
2 |
| Type |
10Gb Ethernet |
| Power Device |
| Power Consumption Operational |
7.5 Watt |
| Processor |
| Installed Qty |
1 |
| Manufacturer |
Solarflare |
| System Requirements |
| Min Operating System |
Red Hat Enterprise Linux 5.8, Red Hat Enterprise Linux 5.9, Red Hat Enterprise Linux 6.2, Red Hat Enterprise Linux 6.3, SuSE Linux Enterprise Server 10 SP4, SuSE Linux Enterprise Server 11 SP2 |
