| Environmental Parameters |
| Min Operating Temperature |
32 °F |
| Max Operating Temperature |
131 °F |
| Humidity Range Operating |
5 – 95% (non-condensing) |
| Header |
| Compatibility |
PC, Unix |
| Manufacturer |
Hewlett-Packard |
| Packaged Quantity |
1 |
| Product Line |
HPE |
| Model |
561T |
| Brand |
HPE |
| Interface Provided |
| Qty |
2 |
| Connector Type |
RJ-45 |
| Type |
10Gb Ethernet |
| Miscellaneous |
| Compliant Standards |
BSMI, BSMI CNS 13438 Class A, EN 61000-3-2, EN 61000-3-3, EN55022 Class A, EN55024, FCC Part 15 A, ICES-003, UL, VCCI V-3 Class A ITE, WEEE |
| Networking |
| Type |
Network adapter |
| Form Factor |
Plug-in card |
| Connectivity Technology |
Wired |
| Data Transfer Rate |
10 Gbps |
| Data Link Protocol |
10 Gigabit Ethernet |
| Remote Management Protocol |
SNMP |
| Compliant Standards |
IEEE 802.1AX, IEEE 802.1Qau, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.3, IEEE 802.3ad (LACP), IEEE 802.3x |
| Status Indicators |
Link/activity, Port status |
| Ports Qty |
2 |
| Features |
Jumbo Frames support, Large Send Offload (LSO), PXE support, Receive Side Scaling (RSS), TCP Segmentation Offload (TSO), Teaming support |
| Interface Type |
PCI Express 2.1 x8 |
| Ports |
| Qty |
2 |
| Type |
10Gb Ethernet |
| Processor |
| Type |
X540 |
| Installed Qty |
1 |
| Manufacturer |
Intel |
| System Requirements |
| Min Operating System |
Citrix XenServer 6.0, Citrix XenServer 6.1, Microsoft Windows MultiPoint Server 2011, Microsoft Windows Server 2008 Datacenter, Microsoft Windows Server 2008 Enterprise, Microsoft Windows Server 2008 Foundation, Microsoft Windows Server 2008 Standard, Microsoft Windows Server 2012, Microsoft Windows Small Business Server 2011 Essentials, Microsoft Windows Small Business Server 2011 Standard, Microsoft Windows Web Server 2008, Red Hat Enterprise Linux 5, Red Hat Enterprise Linux 6, SunSoft Solaris 10, SunSoft Solaris 11, SuSE Linux Enterprise Server 10, SuSE Linux Enterprise Server 11, VMware vSphere 4.1, VMware vSphere 5.0 |
