| Computing power |
4 TOPS |
| Lens type |
Two prime lenses |
| Focal length |
Short-focus lens: 12 mm; Long-focus lens: 25 mm |
| Resolution |
8MP 3840(H)*2160(V) |
| Video compression format |
H.264 and H.265 |
| Protocol |
GB/T 28181, GA/T 1400, and GA/T 920 |
| Web browser |
Google Chrome and Firefox |
| Antenna beamwidth |
Near beam (0–100 m): 90 x 20° (3 dB); medium beam (100–250 m): 24 x 10° (3 dB); far beam (250–500 m): 9 x 8° (3 dB) |
| Operating frequency |
80 GHz (79~81GHz) |
| Power supply |
24 V AC (±10%); DC24V |
| Power consumption |
≤ 30 W |
| Operating temperature |
–30°C to +70°C |
| Body dimensions (H x W x D) |
288.1 mm x 302.5 mm x 233 mm |
| Network port |
One RJ45 10M/100M/1000M adaptive Ethernet port |
| Built-in Illuminators |
8 LED Lights |
| Installation method |
Beam-mounted |
| Waterproof rating |
IP66 |
| Weight |
Maximum: 7 kg |
| Covered lanes |
camera: up to 6 lanes; radar: 10 lanes |
| Detection distance |
Radar and video fusion data: 200m |
| Speed measurement range |
–200 km/h to +200 km/h |
| Velocity resolution |
0.6 km/h |
| Speed Precision |
0.3 km/h |
| Real-time data collection |
Queue length, vehicle flow statistics, time occupancy |
| Management |
Supports multiple functions such as automatic time calibration (through NTP server), auto reboot, running status monitoring, and embedded logs |
| Calibration |
Automatic calibration based on data collected by the radar detector and camera |
