| Memory |
DDR3 128.0 MB |
| Flash type |
SPI NAND FLASH 128.0 MB |
| Focal length |
2.8mm |
| Max Aperture |
F1.6 |
| Image sensor |
1/3″/4MP 2560(H)*1440(V) |
| Lens Aperture type |
Fixed iris |
| Angle of view |
Horizontal: 110°; vertical: 60° |
| IR range |
50m |
| Illumination range |
30m |
| IR Wavelength |
850nm |
| Intelligent identification |
Identify and mark people, cars, bicycles |
| Event detection |
Motion detection, human figure detection and lens blocking detection |
| Behavior analysis |
Tripwire crossing/Intrusion/Area entry or exit |
| Video encoding format |
H.264/H.265/SuperCoding |
| Video encoding channels |
Dual streams |
| Video frame rate |
25 fps/30 fps (configurable) |
| Scene adaptation |
Overcast adaptation |
| Min illumination |
Color: 0.005 lux (F1.2, AGC ON, 1/30s shutter speed); B/W: 0.0025 lux (F1.2, AGC ON, 1/30s shutter speed) or 0 lux (infrared illuminator enabled) |
| Day/Night mode |
Day/Night mode: automatic, color, B/W, and scheduled (default: automatic) Sensitivity: 1–10 (default: 5) Nighttime start time: 18:00:00 by default Daytime start time: 06:00:00 by default Filtering time: 2s to 120s (default: 5s) |
| WDR |
120db |
| White balance |
Auto/Manual/Automatic tracking/Global/Locked |
| HLC/BLC |
Supported/supported |
| Shutter speed |
Shutter speed range: 1/100000s to 1/3s Default value in live video mode: 1/25s |
| SNR |
>45dB |
| Primary stream resolution |
2560×1440(4MP),1920×1080(1080P),1280×720(720P),720×576(D1) |
| Secondary stream resolution |
Secondary stream 1:720×576(D1_PAL),720×480(D1_NTSC),352×288 (CIF_PAL),352×240(CIF_NTSC) |
| Video bit rate |
4MP:512kbit/s to 8Mbit/s; 3MP: 512kbit/s to 8Mbit/s; 1080P:256kbit/s to 8Mbit/s; 720P:256kbit/s to 4Mbit/s; D1:256K to 2Mbit/s; CIF:32K to 1Mbit/s; |
| Digital noise reduction |
2D/3D noise reduction |
| Power type |
DC12V,PoE(IEEE 802.3af) |
| Power consumption |
Maximum:6.6W,typical:1.9W |
| Operating temperature |
-30℃ to 60℃ |
| Storage temperature |
-40℃ to 70℃ |
| Operating humidity |
5% to 95%(non-condensing) |
| Surge protection |
4kV |
| IP rating |
IP67 |
| Equipment Anti Corrosion |
Class C |
| Weight |
Net weight 495g;Gross weight 632g |
| Dimensions |
Device dimensions 259.5*109.5*105mm;Package dimensions 252*121*113mm |
| Language |
Simplified Chinese, English, French, Spanish, Portuguese (Europe), Portuguese (Brazil), Thai, and Turkish |
