| Computing power |
1TOPS |
| Memory |
DDR3 0.5 GB |
| Flash type |
SPI NAND FLASH 512.0 MB |
| Max capacity |
MicroSD card slot that supports microSDHC/microSDXC; maximum memory card capacity: 256 GB |
| Focal length |
2.8-12mm |
| Max Aperture |
F1.6(W)-F3.2(T) |
| Image sensor |
1/2.7″ CMOS/2MP 1920(H)*1080(V) |
| Lens aperture type |
Fixed iris |
| Angle of view |
W ≥:Horizontal95°; T ≤:Horizontal34°. |
| IR range |
50m |
| Digital Zoom/Optical Zoom |
16X/4X |
| Target |
Target detection/Target attribute recognition |
| Target recognition |
Supported |
| Body |
Body detection |
| Vehicle analysis |
Vehicle color/Vehicle type/Vehicle model |
| Traffic flow statistics |
Motor vehicle/Non-motorized vehicle |
| Behavior analysis |
Fast movement/Tripwire crossing/Intrusion/Area entry or exit |
| Crowd flow analysis |
Queue length/Head counting/Crowd flow statistics |
| Non-motorized vehicle |
Supported |
| Defocus |
Supported |
| Alarm information |
No SD card; SD card full; SD card error; Network disconnection; Defocus detection; IP Address Conflict Detection |
| Open OS |
Supported |
| Data openness |
SDK (proprietary protocol)/REST API (proprietary protocol)/GA/T 1400/GB/T 28181 (2011, 2016)/ONVIF Profile S/G/T/M |
| Video encoding format |
MJPEG/H.264/H.265 |
| Video encoding channels |
Triple streams |
| Intelligent encoding |
Extra265/264 |
| Video frame rate |
60/50/30/25 fps (configurable) |
| Scene adaptation |
Backlight adaptation/Overcast adaptation |
| Min illumination |
Color: 0.002 lux (F1.6, AGC ON); B/W: 0.0001 lux (F1.6, AGC ON) or 0 lux (infrared illuminator enabled) |
| Day/Night mode |
Supported; automatic (ICR), color, B/W, and scheduled (default: automatic) |
| WDR |
120db |
| White balance |
Auto/Manual/OnePush |
| HLC/BLC |
Supported/Supported |
| Digital noise reduction |
2D/3D noise reduction |
| Signal-to-Noise Ratio(SNR) |
>45dB |
| Primary stream resolution |
1920×1080(1080P),1280×720(720P) |
| Protocols supported by IPv4 |
TCP, UDP, IPv4, DHCP, DNS, ICMP, IGMP, HTTPS, FTP, SFTP, RTP, RTSP, RTCP, SIP, ARP, SSL, NTP, SNMP (V1/V2/V3), 802.1X, QoS, SMTP, and PPPoE. Note: The northbound protocol needs to adapt to the PPPoE dialup scenario. |
| Protocols supported by IPv6 |
HTTPS,RTP,RTCP,RTSP,Onvif,IPv6,ICMPv6,DHCPv6 |
| Storage port |
MicroSD card slot that supports microSDHC/microSDXC; maximum memory card capacity: 256 GB |
| Alarm port |
2 input port and 1 outputport |
| Network port |
One RJ45 10M/100M adaptive Ethernet port |
| Communication serial port |
RS-485 port |
| Audio port |
Supported (one-channel LINE IN or one-channel external MIC)/Supported (one-channel LINE OUT) |
| Power type |
DC12V,PoE(IEEE 802.3af) |
| Power consumption |
Maximum:12.2W,typical:3.2W |
| Operating temperature |
-30℃ to 55℃ |
| Operating humidity |
5% to 95%(non-condensing) |
| Surge protection |
4kV |
| IP rating |
IP67 |
| IK rating |
IK10 |
| Equipment Anti Corrosion |
Class C corrosion resistance |
| Weight |
Net weight 1.0kg;Gross weight 1.2kg |
| Dimensions |
Device dimensions 330.4mm×108.6mm×92mm;Package dimensions 376mm×139mm×182mm |
