| Fixed Port |
24*10/100/1000Base-T PoE ports (Data/Power), 4*100/1000Base-X uplink SFP slot ports (Data), 1*RS232 console port (115200,N,8,1) |
| Ethernet Port |
10/100/1000Base-T(X), auto-sensing, full/half duplex MDI/MDI-X self-adaption |
| Twisted Pair Transmission |
10BASE-T: Cat3,4,5 UTP(≤100 meter), 100BASE-TX: Cat5 or later UTP(≤100 meter), 1000BASE-T: Cat5e or later UTP(≤100 meter) |
| SFP Slot Port |
Gigabit SFP optical fiber interface, optional single-mode/multi-mode, single/dual fiber optical module (LC) |
| Optical Cable/Distance |
Multi-mode: 850nm / 0 ~ 500M, single-mode: 1310nm/ 0 ~ 40KM, 1550nm /0 ~ 120KM |
| Network Protocol |
IEEE802.3 10BASE-T, IEEE802.3i 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-X, IEEE802.3x |
| Forwarding Mode |
Store and Forward (Full Wire Speed) |
| Switching Capacity |
Switching Capacity |
| Forwarding Rate@64byte |
41.7Mpps |
| MAC |
8K |
| Buffer Memory |
4.1M |
| Jumbo Frame |
10000Bytes |
| LED Indicator |
Power:PWR (green), network: Link(yellow), PoE: PoE (green) |
| MTBF |
≥100000h |
| PoE Port |
Port 1 to 24 IEEE802.3af/at @ POE |
| Power Supply Pin |
Default 1/2 (+), 3/6 (-) |
| Max Power Per Port |
30W; IEEE802.3af/at |
| Total PWR/Input |
400W (AC100-240V) |
| Power Consumption |
Standby:<18W; Full load:<380W |
| Power Supply |
Built-in power supply, AC 100~240V 50-60Hz 5.0A |
| Operation TEMP/Humidity |
-20~+55°C; 5%~90% RH Non-condensing |
| Storage TEMP/Humidity |
-40~+75°C; 5%~95% RH Non-condensing |
| Dimension (L*W*H) |
440*290*44.5mm / 525*390*95mm |
| Net/Gross Weight |
<4.4kg / <5.0kg |
| Installation |
Desktop, 19 inch 1U cabinet |
| Lightning Protection/Protection Level |
Lightning protection: 4KV 8/20us; Protection level: IP30 |
| Certification |
CE mark, commercial, CE/LVD, EN62368-1, FCC Part 15 Class B, RoHS |
| Warranty |
1 year |
