| Fixed Port |
24*10/100Base-TX PoE ports (Data/Power), 2*10/100/1000Base-T uplink RJ45 ports (Data) |
| Ethernet Port |
Port 1-24 can support 10/100Base-TX, Port 25-26 can support 10/100/1000Base-T auto-detection, full/half-duplex MDI/MDI-X auto-sensing |
| Functional Switch |
After opening, port 17-24 can support 10M/250 meters long-distance transmission |
| Twisted Pair Transmission |
10BASE-T: Cat3,4,5 UTP(≤250 meter), 100BASE-TX: Cat5 or later UTP(≤100 meter), 1000BASE-T: Cat5e or later UTP(≤100 meter) |
| Network Protocol |
IEEE802.3 10BASE-T, IEEE802.3i 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T, IEEE802.3x |
| Forwarding Mode |
Store and Forward (Full Wire Speed) |
| Switching Capacity |
14.8Gbps (Non-blocking) |
| Forwarding Rate@64byte |
6.55Mpps |
| MAC |
4K |
| Buffer Memory |
2M |
| Jumbo Frame |
9.2K |
| LED Indicator |
Power: PWR (Green), Network: Link (Green), PoE: PoE (Green) |
| MTBF |
≥100000h |
| PoE Port |
Port 1 to 24 IEEE802.3af/at @PoE |
| Power Supply Pin |
Default 1/2(+), 3/6(-), optional 4/5(+), 7/8(-), 2-pairs power supply |
| Max Power Per Port |
30W, IEEE802.3af/at |
| Total Power/Input |
250W (AC100-240V) |
| Power Consumption |
Standby <20W, Full load <250W |
| Power Supply |
Built-in power supply, AC100~240V 50-60Hz 4.1A |
| Operation TEMP/Humidity |
-20~+55°C; 5%~90% RH Non-condensing |
| Storage TEMP/Humidity |
-40~+75°C; 5%~95% RH Non-condensing |
| Dimension (L*W*H) |
330*204*44mm |
| Net/Gross Weight |
<1.85kg / <2.4kg |
| Installation |
Desktop, wall mounted, rack mounted |
| Lightning Protection/Protection Level |
Lightning protection: 4KV 8/20us; Protection level: IP30 |
| Certification |
CE mark, commercial, CE/LVD EN62368-1, FCC Part 15 Class B, RoHS |
| Warranty |
1 year |
