| Fixed Port |
8*10/100Base-TX PoE ports (Data/Power), 2*10/100Base-TX uplink RJ45 ports (Data) |
| Ethernet Port |
Port 1-10 support 10/100Base-TX auto-sensing, full/half duplex MDI/MDI-X self-adaption |
| Functional Switch |
100m: 100 meters transmission, 250m: 10M/250 meters transmission and VLAN mode. Note: when the switch state changes, it must be restarted before the PoE switch function can take effect |
| Twisted Pair Transmission |
10BASE-TX: Cat5 or later UTP(≤250 meter), 100BASE-TX: Cat5 or later UTP(≤100 meter) |
| Network Protocol |
IEEE802.3 10BASE-T, IEEE802.3i 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3x |
| Forwarding Mode |
Store and Forward (Full Wire Speed) |
| Switching Capacity |
2Gbps (Non-blocking) |
| Forwarding Rate@64byte |
1.488Mpps |
| MAC |
2K |
| Buffer Memory |
1.25Mb |
| Jumbo Frame |
1536bytes |
| LED Indicator |
Power:PWR (Green), network: L/A (Yellow), PoE: PoE (Green), Functional switch: EXTEND (Green) |
| MTBF |
≥100000h |
| PoE Port |
Port 1 to 8 POE+ |
| Power Supply Pin |
1/2(+), 3/6(-) |
| Max Power Per Port |
30W, IEEE802.3af/at |
| Total Power/Input Voltage |
100W/ (AC100-240V) |
| Power Consumption |
Standby <5W, Full load <100W |
| Power Supply |
Built-in power supply, AC100~240V 50-60Hz, 2.2A |
| Operation TEMP/Humidity |
-20~+55°C; 5%~90% RH Non-condensing |
| Storage TEMP/Humidity |
-40~+75°C; 5%~95% RH Non-condensing |
| Dimension (L*W*H) |
195*130*40mm |
| Net/Gross Weight |
0.75kg / 1.0kg |
| Installation |
Desktop, wall-mounted |
| Lightning Protection/Protection Level |
Lightning protection: 4KV 8/20us, Protection level: IP30 |
| Certification |
CE mark, commercial, CE/LVD EN62368-1, FCC Part 15 Class B, RoHS |
| Warranty |
1 year |
