| Computing power |
1TOPS |
| Memory |
DDR4 1.0 GB |
| Flash type |
SPI NAND FLASH 512.0MB |
| Max capacity |
MicroSD card slot that supports microSDHC/microSDXC; maximum memory card capacity: 256 GB |
| Focal length |
2.8-12mm Varifocal Motorized |
| Max Aperture |
F1.4(W)-F2.2(T) |
| Image sensor |
1/1.8″CMOS/8MP 3840(H)*2160(V) |
| Lens aperture type |
P-iris (DC iris+Hall sensor) |
| Angle of view |
Horizontal:47.5°(T) to 102.8°(W);Vertical:26.6°(T) to 54.9°(W) |
| IR range |
40m |
| Digital/optical zoom |
Supported |
| Target |
Target detection/Target enhancement/Target attribute recognition |
| Target recognition |
Supported |
| Person |
Person detection |
| License plate recognition |
License plates from the Chinese Mainland |
| Vehicle analysis |
Vehicle color/Vehicle type/Vehicle model |
| Traffic flow statistics |
Motor vehicle/Non-motorized vehicle/Pedestrian |
| Behavior analysis |
Fast movement/Tripwire crossing/Intrusion/Area entry or exit /Loitering |
| Crowd flow analysis |
Queue length/Head counting/Crowd flow statistics |
| Non-motorized vehicle |
Supported |
| Multi-algorithm switchover |
Supported |
| Defocus |
Supported |
| Open OS |
Supported |
| Data openness |
SDK (proprietary protocol)/REST API (proprietary protocol)/GA/T 1400/GB/T28181(2011, 2016) |
| Video encoding format |
MJPEG/H.264/H.265 |
| Video encoding channels |
Triple streams |
| Intelligent encoding |
Extra265/264 |
| Video frame rate |
25or 20fps (configurable) |
| Scene adaptation |
Backlight adaptation/Overcast adaptation |
| Min illumination |
Color: 0.002lux(F1.2,AGC ON, 1/30sshutter speed); B/W: 0.0005lux (F1.2,AGC ON, 1/30sshutter speed) or 0 lux(infrared illuminator enabled) |
| Day/Night mode |
Supported; automatic (ICR), Color, B/W, and scheduled (default: automatic); sensitivity level: high (default), medium, and low; image triggering/internal triggering |
| WDR |
120db |
| White balance |
Auto/Manual/OnePush |
| Highlight compensation |
Supported |
| Digital noise reduction |
2D/3D noise reduction |
| Defogging |
Supported |
| EIS |
Supported. Sensitivity levels are not supported |
| Protocols supported by IPv4 |
TCP, UDP, IPv4, DHCP, DNS, ICMP, IGMP, HTTPS, FTP, SFTP, RTP, RTSP, RTCP, SIP, ARP, SSL, NTP, SNMP (V1/V2/V3), 802.1x,QoS, SMTP, and PPPoE. Note: The northbound protocol needs to adapt to the PPPoE dialup scenario |
| Protocols supported by IPv6 |
HTTPS,RTP,RTCP,RTSP,Onvif,IPv6,ICMPv6,DHCPv6 |
| Storage port |
MicroSD card slot that supports microSDHC/microSDXC; maximum memory card capacity: 256GB |
| Alarm port |
2 input port and 1output port |
| Network port |
One RJ45 10M/100Madaptive Ethernet port |
| Communication serial port |
RS-485 port |
| Audio port |
Supported (one-channel LINE IN and one-channel built-in MIC)/Supported (one-channel LINE OUT) |
| Power type |
DC12V,AC24V,PoE(IEEE 802.3af) |
| Power consumption |
Maximum:12W,typical:4.5W |
| Operating temperature |
-30℃ to 55℃ |
| Operating humidity |
5% to 95%(non-condensing) |
| Surge protection |
4kV |
| IP rating |
IP67 |
| Equipment Anti Corrosion |
Class C corrosion resistance |
| IK rating |
IK10 |
| Weight |
Net weight 1.2kg;Grossweight 1.5kg |
| Dimensions |
Device dimensions φ149.4mm×130.8mm;Package dimensions 200.5mm×188mm×182.5mm |
