HPE ProLiant Server 741066-B21

< tbody >

Model:	741066-B21 – HPE ProLiant DL560 Gen9 Server
Detail:	HPE ProLiant DL560 Gen9 E5-4640v3 4P 128GB-R P840/4GB 16SFF 2x1200W RPS Perf Server

Description

HPE 741066-B21 Specification HPE ProLiant Server 741066-B21
Energy efficiency	ENERGY STAR® qualified
Processor	Intel® Xeon® E5-4640 v3 (12 core, 1.9 GHz, 30MB, 105W)
Number of processors	4
Processor core available	12
Processor cache	30MB L3
Processor speed	1.9GHz
Form factor (fully configured)	2U
Form factor chassis	Rack
Power supply type	(1) 1200W Platinum Plus hot plug power supply kit Common Slot
Expansion slots	(7) PCIe 3.0 For detail descriptions reference the QuickSpecs
Memory, maximum	3.0TB
Memory, standard	128GB (8x16GB) RDIMM
Memory slots	48 DIMM slots
Memory type	2R x4 PC4-2133P-R
Memory protection features	Advanced ECC and DIMM Address/Parity Protection Memory Online Spare Mode Memory Lock Step Mode
Included hard drives	(16) SFF None ship standard Supports up to (16) SFF SAS/SATA hot plug drives. Can be expanded to a maximum of 24 SFF drives.
Optical drive type	Optional
System fan features	Hot plug redundant standard
Network controller	(1) 10Gb 533FLR-T FlexFabric Adapter 2 Ports per controller
Storage controller	(1) Smart Array P840/4GB FBWC
Product dimensions (H x W x D)	17.54 x 29.5 x 3.44 in
Weight	61 lb
Infrastructure management	iLO Management (standard), Intelligent Provisioning (standard), iLO Advanced (optional), HP OneView Advanced (optional), HP Insight Control (optional)
