| Image sensor |
1/3” or 1/2.7” CMOS |
| Maximum Resolution |
1920 (H)*1080 (V) / 2880 (H)*1620 (V) |
| Lens |
2.8mm / 3.6mm |
| Effective pixels |
Default 2MP/5MP 25FPS（P)/30FPS(N) |
| Signal system |
PAL/NTSC（switched by OSD） |
| Day-night mode |
IR Cut Filter |
| S/N Ratio |
≥50DB |
| Minimum illumination |
0.02lux@F2.0 |
| BLC |
AUTO |
| AWB |
AUTO |
| AES |
AUTO |
| OSD language (6) |
English/Chinese/Russian/Japanese/Korean |
| IR Range |
20m |
| Video output |
AHD/TVI/CVI/CVBS |
| Video recording takes up space |
1 min≈35.2MB（2.8mm/3.6mm lens） |
| Operating temperature |
-20℃ – 60℃ |
| Power type |
12 VDC 0.5A |
| Power consumption |
Day ≦3W, Night ≦6W |
| Operating humidity |
95% or Less (Non-Condensing) |
| IP rating |
IP66 |
| Weight |
283g |
| Size (With Package) |
110mm*110mm*89mm (L*W*H) |
