WS-C3650-48TD-L Datasheet
Original price was: $9,263.00.$2,289.00Current price is: $2,289.00.
| Model: | WS-C3650-48TD-L Datasheet – Catalyst 3650 Switch |
| Detail: | Cisco Catalyst 3650 48 Port Data 2x10G Uplink LAN Base |
PDF ATTACHMENT : ws-c3650-48td-l-datasheet
- Description
Description
Cisco Catalyst WS-C3650-48TD-L Datasheet is accessible on our Gntme.com site stage at the least expensive rate as we are having Cisco Switches available to be purchased.
The Cisco Catalyst® 3650 Series is the up and coming age of big business class independent and stackable access-layer switches that give the establishment to full intermingling between wired and remote on a solitary stage. The Cisco Catalyst 3650 is based on the high-level Cisco StackWise®-160 and exploits the new Cisco® Unified Access Data Plane (UADP) application-explicit incorporated circuit (ASIC). This switch can empower uniform wired-remote approach authorization, application permeability, adaptability, application streamlining, and unrivaled strength. The Cisco switch Catalyst 3650 Series uphold full IEEE 802.3at Power over Ethernet Plus (PoE+), and offer particular and field-replaceable excess fans and force supplies. They can help you increment remote profitability and diminish your TCO.
We the Gear Net Technologies are a Dubai-based organization having 11 years of involvement with conveying and providing IT, systems administration, and security item and administrations across the globe. We are offering a wide range of Cisco arrangements at the most minimal value conceivable. With the assistance of the value show, you can undoubtedly contrast each switch and its arrangements and costs, and make an inference which is your best purchase pick. At any rate, we will be consistently there for you, in the event that you have any sort of inquiries with respect to the switch or its buy.
WS-C3650-48TD-L Datasheet Specification |
|
|
Enclosure type |
Rack-mountable – 1U |
|
Ports |
48 x 10/100/1000 + 2 x 10G SFP+ & 2 x 1G SFP |
|
Network management Interface |
· Ethernet management port: RJ-45 connectors, 4-pair Cat-5 UTP cabling |
|
Available PoE Power |
None |
|
Switching Capacity |
176Gbps |
|
Maximum stacking number |
9 |
|
Stack Bandwidth |
160Gbps |
|
Forwarding Performance |
104.16Mpps |
|
FNF entries |
Disabled (IP base license required) |
|
Maximum VLANs IDs |
255 |
|
MAC Address Table Size |
32K |
|
CPU |
Multicore CPU |
|
RAM |
4 G |
|
Flash Memory |
2 G |
|
Wireless |
|
|
Number of AP per switch/stack |
50 |
|
Number of wireless clients per switch/stack |
1000 |
|
Total number of WLANs per switch |
64 |
|
Wireless bandwidth per switch |
up to 40Gbps |
|
Supported Aironet AP series |
3700, 3600, 3500, 2600, 1600, 1260, 1140, 1040 |
|
Expansion / Connectivity |
|
|
Console ports |
USB (Type-B), Ethernet (RJ-45) |
|
Expansion Slot(s) |
power redundant slot |
|
Accessory & Rack Moubt Kits |
· ACC-KIT-T1: Accessory kit |
|
Stacking module & cable |
· C3650-STACK-KIT: Stack Module |
|
Power supply |
PWR-C2-1025WAC |
|
Power Device |
Power supply – redundant – plug-in module |
|
Power Redundancy |
optional |
|
Voltage range (Auto) |
100V-240V |
|
Power Consumption of standalone (in Watts) |
93.9 (max) |
|
Miscellaneous |
|
|
Width |
17.5 Inches (44.5 cm) |
|
Depth |
17.625 Inches (44.8 cm) |
|
Height |
1.73 Inches (4.4 cm) |
|
Shipping Weight |
17.49 Kg |
|
Rack Mounting Kit |
optional |
|
MTBF in hours |
527,580 |
|
Compliant Standards |
· IEEE 802.1D Spanning Tree Protoco |
|
System software / license |
|
|
System software |
IOS LAN Base (Upgradable) |
|
EnergyWise license |
ENERGY-MGMT, ENERGY-MGT-100-K9 |
|
Software license |
· C3650-48-L-S : LAN Base to IP Base RTU paper license |
|
Access Point Licenses |
· L-LIC-CT3650-UPG: Primary upgrade license SKU for Cisco 3650 wireless controller (e-delivery) |
|
Features |
· EEM · RPS Support · IP service-level agreements (SLAs) · Advanced IP unicast routing protocols · Jumbo Frames · VLANS · Voice Vlan · VTPv2 · CDPv2 · LLDP · 802.3ad LACP and PAgP · PVST/PVST+ · 802.1W/802.1S · Port Fast/Uplink Fast · Dynamic Trunking Protocol (DTP) · port CoS Trust and Override · Trusted Boundary · ACL Classification · ingress Policing · Auto QoS · Per VLAN policies · 802.1p queues · Scheduling · Priority Queuing · Configure CoS Priority Queues · Configure CoS Priority Queues · Configure Queue Weights · Configure Buffers and Thresholds · Class & Policy Maps · Modify CoS and DSCP Mapping · Weighted Tail Drop · IGMPv1,v2,v3 and MLDv1, v2 · DHCP server · DSCP transparency · HSRP, VRRP, BLGP · RIPv1, v2 EIGRP, PIM OSPF, OSPFv3, EIGRPv6, BGPv4, IS-ISv4 · VRF-lite · PIM-SM/DM, PIM sparse-dense mode, SSM · Flexible Netflow |
|
Advanced Network security |
· Port security · DHCP snooping · Dynamic ARP inspection (DAI) · IP source guard · The Unicast Reverse Path Forwarding (uRPF) |
|
Management |
· BRIDGE-MIB · CISCO-AUTH-FRAMEWORK-MIB · CISCO-VTP-MIB · EtherLike-MIB · HC-RMON-MIB · IEEE8021-PAE-MIB · IEEE8023-LAG-MIB |
|
Technical Support and Services |
· Cisco SMARTnet Service · Cisco Smart Foundation Service · Cisco SP Base Service · Cisco Focused Technical Support Services |
|
Environmental Ranges |
|
|
With AC power supply |
|
|
Operating temperature up to 5000 ft (1500 m) |
23ºF to 113ºF (-5ºC to +45ºC) |
|
Operating temperature up to 10,000 ft (3000 m) |
23ºF to 104ºF (-5ºC to +40ºC) |
|
Short-term exception at sealevel with single fan failure |
23ºF to 113ºF (-5ºC to +45ºC) |
|
Short-term exception up to 5000 feet (1500 m) |
23ºF to 122ºF (-5ºC to 50ºC) |
|
Short-term exception up to 10,000 feet (3000 m) |
23ºF to 113ºF (-5ºC to 45ºC) |
|
With DC power supply |
|
|
Operating temperature up to 6000 ft (1800 m) |
23ºF to 113ºF (-5ºC to +45ºC) |
|
Operating temperature up to 10,000 ft (3000 m) |
23ºF to 104ºF (-5ºC to +40ºC) |
|
Operating temperature up to 13,000 ft (4000m) |
23ºF to 95ºF (-5ºC to 35ºC) |
|
Short-term exception up to 6,000 feet (1800 m) |
23ºF to 131ºF (-5ºC to +55ºC) |
|
Short-term exception up to 10,000 feet (3000 m) |
23ºF to 122ºF (-5ºC to +50ºC) |
|
Short-term exception up to 13,000 feet (4000 m) |
23ºF to 113ºF (-5ºC to +45ºC) |
|
Short-term exception at sealevel with single fan failure |
23ºF to 113ºF (-5ºC to +45º) |
|
Storage environment |
-40ºF to 160ºF (-40ºC to 70ºC) |
|
Operating altitude |
Up to 16,400 Feet (Up to 5000m) |
|
Storage altitude |
Up to 16,400 Feet (Up to 5000m) |
|
Operating relative humidity |
5% to 96% noncondensing |
|
Storage relative humidity |
5% to 96% noncondensing |
|
Short-term exception at sealevel with single fan failure |
23ºF to 113ºF |
|
Storage environment |
-40ºF to 160ºF |
