| Computing power |
1 TOPS |
| Memory |
1.0 GB |
| Flash type |
512.0 MB |
| Focal length |
5–165 mm |
| Max aperture |
F1.6 (W) to F4.4 (T) |
| Image sensor |
1/2.7″ CMOS/4MP 2560(H)*1440(V) |
| Max.resolution |
2560(H)*1440(V) |
| IR range |
100 m |
| Zoom |
Digital Zoom: 16X; Optical zoom: 33X |
| PTZ rotation angle |
Pan: 0° to 360° Tilt: –90° to +90° |
| Pan speed |
Manual: 0.1–40°/s Speed for moving to the preset position: 40°/s |
| Tilt speed |
Manual: 0.1–30°/s Speed for moving to the preset position: 30°/s |
| Behavior analysis |
Fast movement/Tripwire crossing/Intrusion/Area entry or exit /Loitering |
| Crowd flow analysis |
Queue length/Head counting/Crowd flow statistics |
| Defocus |
Supported |
| Open OS |
Supported |
| Data openness |
SDK (proprietary protocol)/REST API (proprietary protocol)/Onvif Profile G/S/T |
| Video encoding format |
MJPEG/H.264/H.265 |
| Video encoding channels |
Triple streams |
| Intelligent encoding |
Extra265/264 |
| Video frame rate |
4-megapixel: 30 fps or 25 fps |
| Scene adaptation |
Backlight adaptation/Overcast adaptation/Speed adaptation |
| OSD |
Camera ID, time |
| Min illumination |
Color: 0.005 lux (F1.2, AGC ON, 1/30s shutter speed); B/W: 0.0005 lux (F1.2, AGC ON, 1/30s shutter speed) |
| Day/Night mode |
Supported; automatic (ICR)/Color/B/W (default: automatic) Sensitivity level: high (default), medium, and low Image triggering /Internal triggering |
| Signal-to-Noise Ratio(SNR) |
>45dB |
| Primary stream resolution |
2560×1440(4MP),2048×1536(3MP),1920×1080(1080P),1280×720(720P) |
| Secondary stream resolution |
Secondary stream 1: 720×576(PAL)，720×480(NTSC)，352×288(PAL)，352×240(NTSC)； Secondary stream 2: 352×288(PAL)，352×240(NTSC) |
| Video bit rate |
Only for H.264 and H.265 1080P-4K 512Kbps – 16Mbps 720P 384Kbps – 8Mbps D1 256K – 4Mbps CIF 32K – 1Mbps |
| WDR |
120 dB |
| White balance |
Auto/Auto tracking/Manual/OnePush |
| Highlight compensation |
Supported |
| Digital noise reduction |
2D/3D noise reduction |
| Defogging |
Supported |
| EIS |
Supported Sensitivity levels are not supported. |
| Protocols supported by IPv4 |
TCP,UDP,IPv4,DHCP,DNS,ICMP,IGMP,HTTPS,FTP,SFTP,RTP,RTSP, RTCP,SIP,ARP,SSL,NTP,SNMP(V1/V2/V3),802.1x,QoS,SMTP,PPPOE |
| Protocols supported by IPv6 |
HTTPS,RTP,RTCP,RTSP,Onvif,IPv6,ICMPv6,DHCPv6 |
| Alarm port |
2 input port and 1 output port |
| Network port |
One RJ45 10M/100M adaptive Ethernet port |
| Communication serial port |
1 universal half-duplex RS-485 port |
| Audio port |
Supported (one-channel LINE IN or one-channel external MIC)/Supported (one-channel LINE OUT) |
| Power type |
AC100V～AC240V |
| Power consumption |
Maximum: 75 W; typical: 39 W |
| Operating temperature |
–30°C to +60°C (excluding the water tank) |
| Operating humidity |
≤ 95% (non-condensing) |
| Protection |
IP68 |
| Surge protection |
2 kV |
| Certificate |
ATEX, IECEx |
| Explosion-proof Marking |
ATEX: Ex Ⅱ2G Ex db ⅡC T6 Gb/Ex Ⅱ2D Ex tb ⅢC T80 ºC Db IECEx: Ex db ⅡC T6 Gb/Ex tb ⅢC T80 ºC Db |
| Weight |
Net weight 36.3 kg;Gross weight 48 kg |
| Dimensions |
Device dimensions 390×295×420mm;Package dimensions 605×665×495mm |
| Wiper |
Yes |
| Explosion-proof level |
IIC, IIIC |
| IP rating |
IP66 |
| Product material |
316L stainless steel |
| Operating temperature |
0°C＜T≤60°C (depends on cleanning agent) |
| Power supply voltage |
100V-240V a.c. 50/60Hz or 24V a.c. 50/60Hz or 24V d.c. or PoE++(48V d.c.) , choose one when ordering |
| Maximum power consumption |
52 W |
| Dimensions (H x W x D) |
600mm x 330.5 mm x 362.3 mm |
| Built-in accessories |
Pump, water storage tank 15Liter |
| Speed range |
1-600rpm |
| Flow rate |
1000ml/min |
| Weight |
23.6 kg |
| Cable outlet quantity/specification |
1 x M25 x 1.5″ cable outlet |
| Installation mode |
on the ground |
