Product Details
U11Z11CFG2
AED2,781.00
< tbody >
| Model: | U11Z11CFG2 eSpace U1900 Series Unified Gateways |
| Detail: | eSpace U1911(AC,1 SCU,1 MTU,16G SD Card,2E1 with cable, 50 Voice Subscriber,4 Voice Mail Concurrent,16 Voice Conference Concurrent Subscribers) |
Description
eSpace U1911 Specifications |
||
| Maximum number of users | 100 (a maximum of 100 SIP users or 64 FXS ports for analog users) | |
| Terminal type | Analog phones, IP phones, video phones and soft clients | |
| Port | 24 FXO ports, 6 E1/T1 ports, or 8 BRI ports | |
| Trunk protocol | SS7, R2, PRI, QSIG, SIP, BRI | |
| Codec | G.711a/μ, G.729, G.729a, G.729b, G.729ab, iLBC, G.722, G.722.1, G.722.2 | |
| Number of meeting participants | A maximum of 60 meeting participants which can be allocated to 20 meeting halls (each hall can support up to 60 participants by maximum) | |
| Built-in voice mail box | A maximum of 12 built-in voice mail channels concurrently Built-in 16G SD storage card | |
| Power supply | AC: 100 V to 240 V, 50 Hz/60 Hz DC: –38.4 V to –60 V (typical value: –48 V) |
|
| Maximum power consumption | 150 W (full configuration) | |
| Dimensions (H * W * D) | Standard 19-inch 1 U subrack 44 mm * 442 mm * 310 mm |
|
| Weight | 8 kg (full configuration) | |
| Environment | Temperature | Storage temperature: –40° C to +70° C Long-term operating temperature: 0° C to 45° C Short-term operating temperature: –5° C to +55° C |
| Relative humidity | 5% to 95% (without condensation) | |
| Dustproof | Less than 180 mg/m³ dust in the air (Dustproof measures should be taken in the work environment) | |
| System Reliability | 99.995% | |
| Maintainability | Remote maintenance, automatic configuration, log collection, and Daylight Saving Time (DST) | |
| Manageability | Centralized/remote equipment management, signaling tracing, resource management, alarm management, and quick deployment | |
