| Computing power |
1TOPS |
| Memory |
DDR31.0GB |
| Flash type |
SPI NAND FLASH 256.0 MB |
| Focal length |
5.3-175mm Varifocal Motorized |
| Max Aperture |
F1.6(W)-F4.4(T) |
| Image sensor |
1/2.7″ CMOS Progressive Scan/5MP 2880(H)*1620(V) |
| Lens aperture type |
DC iris+Hall sensor |
| Angle of view |
Horizontal AoV: 2.3° (T) to 55.8° (W) Vertical AoV: 1.3° (T) to 40.2° (W) AoV deviation: ≤ 5% |
| IR range |
150m |
| Illumination distance |
30m |
| Zoom |
Digital zoom: 16x; Optical zoom: 33x |
| IR Wavelength |
850 nm |
| DORI D(m) W |
106.0 |
| DORI D(m) T |
2700.0 |
| DORI O(m) W |
42.7 |
| DORI O(m) T |
1088.7 |
| DORI R(m) W |
21.2 |
| DORI R(m) T |
540 |
| DORI I(m) W |
10.6 |
| DORI I(m) T |
270 |
| PTZ rotation angle |
Pan: 0°～360° Continues Vertical-15°～90° |
| Pan speed |
Maximum speed for rotating to a preset position: 100°/s; manual control speed: 0.1°/s to 100°/s Note: The PTZ rotation speed needs to be limited in the case of low temperature. Temperature for entering the speed limit mode: –20°C Temperature for exiting the speed limit mode: –10°C Max pan speed: 30°/s Max tilt speed: 20°/s |
| Tilt speed |
Maximum speed for rotating to a preset position: 80°/s; manual control speed: 0.1° /s to 80°/s Note: The PTZ rotation speed needs to be limited in the case of low temperature. Temperature for entering the speed limit mode: –20°C Temperature for exiting the speed limit mode: –10°C Max pan speed: 30°/s Max tilt speed: 20°/s |
| Park action |
Supported |
| Tour |
Supported |
| Preset position |
512 (including one home position) |
| Home position |
One home position |
| Electronic Image Stabilization (EIS) |
Supported |
| Behavior analysis |
Fast movement/Tripwire crossing/Intrusion/Area entry or exit /Loitering |
| Crowd flow analysis |
Queue length/Head counting/Crowd flow statistics/Attendance |
| Intelligent tracking |
Supported |
| Defocus |
Supported |
| Basic Event |
Motion detection/Abandoned object detection/Removed object detection |
| Alarm information |
HTTPS certificate expiration/SDK certificate expiration/App verification certificate expiration/Level-2 app verification certificate expiration/Mobile app certificate expiration/SDK root certificate expiration/SDK revocation certificate expiration/GB 35114 certificate expiration/802.1X certificate expiration/Mobile app root certificate expiration/Log certificate expiration/Network disconnection/Network packet receiving anomaly/Full hard disk/Hard disk removal/Failure to write data to disks/Media stream interrupted/Log saving anomaly /Flash read/write/Temperature sensor fault/Hot swapping of network adapters/Video loss/Lens PT optocoupler fault/PTZ configuration anomaly/PTZ optocoupler fault/Position change |
| Open OS |
Supported |
| Data openness |
SDK (proprietary protocol)/REST API (proprietary protocol)/GA/T 1400/GB/T 28181 (2011, 2016) /ONVIF Profile S/G/T/M |
| Video encoding format |
MJPEG/H.264/H.265 |
| Video encoding channels |
Triple streams |
| Intelligent encoding |
Extra265 |
| Video frame rate |
Configurable (30 fps or 25 fps); default value: 25 fps |
| Scene adaptation |
Backlight adaptation/Overcast adaptation |
| Min illumination |
Color: 0.005 lux (F1.2, AGC ON, 1/30s shutter speed); B/W: 0.0005 lux (F1.2, AGC ON, 1/30s shutter speed) or 0 lux (infrared illuminator enabled) |
| Day/Night mode |
Day/Night mode: automatic (ICR), color, B/W, and scheduled (default: automatic) Trigger mode: image triggered or internal signal triggered (default: image triggered) |
| WDR |
120dB |
| White balance |
Auto/Manual/OnePush |
| HLC/BLC |
Supported/Supported |
| Shutter speed |
Shutter speed range: 1/100000s to 1/25s Default value in live video mode: 1/25s Default value in target checkpoint mode: 1/25s Default value in micro checkpoint mode: 1/25s Default value in behavior analysis mode: 1/25s |
| SNR |
>45dB |
| Primary stream resolution |
2880×1620(5MP),2560×1440(4MP),2304×1296(3MP),1920×1080 (1080P),1280×720(720P),720×576(PAL) |
| Secondary stream resolution |
Secondary stream 1:720×576(PAL),720×480(NTSC),352×288(PAL), 352×240(NTSC); Secondary stream 2:352×288(PAL),352×240(NTSC) |
| Video bit rate |
1080p to 4K: 512 kbit/s to 16 Mbit/s 1080p: 256 kbit/s to 16 Mbit/s 720p: 256 kbit/s to 8 Mbit/s D1: 256 kbit/s to 4 Mbit/s CIF: 32 kbit/s to 1 Mbit/s |
| Digital noise reduction |
2D/3D noise reduction |
| Audio encoding format |
G.711a/G.711u/G.726/OPUS/AAC |
| Audio sampling rate |
G.711a/G.711u/G.726:8K OPUS:8K/12K/16K/24K/48K AAC:8K/16K/22. 05K/24K/32K/44.1K/48K |
| Audio bit rate |
G.711a/G.711u: 64 kbit/s; G.726: configurable (16/24/32/40 kbit/s); OPUS: configurable (16/24/32/40/64/96/128/160/192/224/256/288 kbit/s) AAC: 8 kHz sampling rate: 16/22/24/32/48 kbit/s 16 kHz sampling rate: 24/32/48/64/96 kbit/s 22.05/24/32 kHz sampling rate: 32/48/64/96/128 kbit/s 44.1/48 kHz sampling rate: 48/64/96/128 /256 kbit/s |
| Protocols supported by IPv4 |
TCP, UDP, IPv4, DHCP, DNS, ICMP, IGMP, HTTP,HTTPS, FTP, SFTP, RTP, RTSP, RTCP, SIP, ARP, SSL, NTP, SNMP (V1/V2/V3), 802.1X, QoS, SMTP, and PPPoE. Note: The northbound protocol needs to adapt to the PPPoE dialup scenario. |
| Protocols supported by IPv6 |
HTTP,HTTPS,RTP,RTCP,RTSP,Onvif,IPv6,ICMPv6,DHCPv6 |
| Web Browser |
32- or 64-bit Windows 7, Windows 8, or Windows 10 Google Chrome: 32-bit Google Chrome 38–49 (The IE Tab plug-in must be installed for Google Chrome 46–49.) 32- or 64-bit Google Chrome 50+ Internet Explorer: 32-bit Internet Explorer 10 and 11 Firefox: 32- bit Firefox 35–51 32- or 64-bit Firefox 70+ Microsoft Edge: 32- or 64- bit Microsoft Edge 50+ Restrictions: Compatibility problems may occur on the Firefox browser. (Pages may be out of order for a short time.) |
| Media security |
Supports web- or SDK-based media stream encryption; supports a maximum of two channels of encrypted media streams; media stream encryption and full intelligence, target recognition, or image upload through SFTP/FTP cannot be enabled at the same time; after the intelligent analysis function is enabled, only one-channel stream encryption is supported; supports encrypted storage of data in SD cards. By default, RTSP uses MD5 digest authentication. |
| Video digital watermark |
Supported |
| Image digital watermark |
Supported |
| User rights |
Three user roles: administrator, advanced operator, and common operator |
| Security mode |
User name and password authentication, 802.1X authentication, and HTTPS digital certificate |
| Secure boot |
Supported |
| System intrusion detection |
Promiscuous network adapter detection;Sensitive system file detection;Unauthorized super account detection;Botnet detection; Rootkit detection;Trustlisted program detection ;Privilege escalation detection |
| Storage port |
One microSD card slot that supports microSDHC/microSDXC (maximum memory card capacity: 256 GB) |
| Alarm port |
2 input port and 1 output port |
| Network port |
One RJ45 10M/100Madaptive Ethernet port |
| Audio port |
Supported (one-channel LINE IN and one-channel built-in microphone)/Supported (one- channel LINE OUT or one-channel speaker) |
| Power consumption |
Maximum:22.3W,typical:8.9W |
| Operating temperature |
–30°C to +60°C |
| Storage temperature |
-40℃ to 70℃ |
| Operating humidity |
5% to 95%(non-condensing) |
| Surge protection |
6kV |
| IP rating |
IP66 |
| Equipment Anti Corrosion |
Class C |
| Weight |
Net weight 2.6kg;Gross weight 4.5kg |
| Dimensions |
Device dimensions φ202.6mm*260mm；;Package dimensions 285mm*285mm*375mm |
| Language |
Simplified Chinese, English, French, Spanish, Portuguese (Europe), Portuguese (Brazil), Thai, Italian, and Turkish |
