| Computing power |
1 TOPS |
| Focal length |
5.3-175mm Varifocal Motorized |
| Max Aperture |
F1.6(W)-F4.4(T) |
| Image sensor |
1/2.7″ CMOS/5MP 2880(H)*1620(V) |
| IR range |
150m |
| Illumination distance |
30m |
| Digital Zoom/Optical Zoom |
16x/33x |
| PTZ rotation angle |
Pan: 0°～360° Vertical-15°～90° |
| Park action |
Supported |
| Tour |
Supported |
| Home position |
One home position |
| Target |
Target detection/Not supported;/Target attribute recognition |
| Person |
Person detection |
| Behavior analysis |
Fast movement/Tripwirecrossing/Intrusion/Areaentry or exit/Loitering |
| Crowd flow analysis |
Queue length/Head counting/Crowd flow statistics/Attendance |
| Intelligent tracking |
Supported |
| Defocus |
Supported |
| Open OS |
Supported |
| Data openness |
SDK (proprietary protocol)/REST API (proprietary protocol)/GA/T 1400/GB/T 28181 (2011, 2016)/ONVIF Profile S/G/T/M |
| Video encoding format |
MJPEG/H.265 |
| Video encoding channels |
Triple streams |
| Video frame rate |
Configurable (30 fps or 25 fps); default value: 25 fps |
| Intelligent encoding |
Extra265 |
| Scene adaptation |
Backlight adaptation/Overcast adaptation |
| WDR |
120dB |
| HLC/BLC |
Supported/Supported |
| Digital noise reduction |
2D/3D noise reduction |
| Protocols supported by IPv4 |
TCP, UDP, IPv4, DHCP, DNS, ICMP, IGMP, HTTPS, FTP, SFTP, RTP, RTSP, RTCP, SIP, ARP, SSL, NTP, SNMP (V1/V2/V3), 802.1X, QoS, SMTP, and PPPoE. Note: The northbound protocol needs to adapt to the PPPoE dialup scenario. |
| Protocols supported by IPv6 |
HTTPS, RTP, RTCP, RTSP, ONVIF, IPv6, ICMPv6, and DHCPv6 |
| Network port |
One RJ45 10M/100M adaptive Ethernet port |
| Audio port |
Supported (one-channel LINE IN and one-channel built-in MIC)/Supported (one-channel LINE OUT or one-channel Speaker) |
| Power type |
AC24V,POE(IEEE 802.3At) |
| Power consumption |
Maximum:22.3W,typical:8.9W |
| Operating humidity |
5% to 95%(non-condensing) |
| Surge protection |
6kV |
| IP rating |
IP66 |
| Weight |
Net weight 2.6kg;Gross weight 4.5kg |
| Dimensions |
Device dimensions 202.6mm*202.6mm*260mm;Package dimensions 285mm*285mm*375mm |
