| Computing power |
1.0 TOPS |
| Memory |
DDR3 256.0 MB |
| Flash type |
SPI NAND FLASH 256.0 MB |
| Focal length |
2.7-12mm |
| Max Aperture |
F1.2 |
| Lens Aperture Type |
Auto-IRIS |
| Image sensor |
1/2.7″ CMOS/5MP 2880(H)*1620(V) |
| Angle of view |
Horizontal:32°(T) to 95°(W);Vertical:18°(T) to 52°(W) |
| IR range |
30m |
| Illumination distance |
30m |
| IR Wavelength |
850nm |
| Target |
Target detection |
| Person |
Person detection |
| Behavior analysis |
Fast movement/Tripwire crossing/Intrusion/Area entry or exit /Loitering/Parking detection |
| Crowd flow analysis |
Queue length/Head counting/Crowd flow statistics/Absence detection |
| Data openness |
GB28181/SDK (proprietary protocol)/REST API (proprietary protocol)/GA/T 1400/ONVIF Profile S/G/T/M |
| Video encoding format |
H.264/H.265/SuperCoding |
| Video encoding channels |
Dual streams |
| Video frame rate |
30/25fps |
| Scene adaptation |
Overcast adaptation |
| WDR |
130db |
| HLC/BLC |
Supported/Supported |
| SNR |
>50dB |
| Primary stream resolution |
2880×1620(5MP),2560×1440(4MP),2304×1296(3MP),1920×1080 (1080P),1280×720(720P),720×576(D1_PAL) |
| Secondary stream resolution |
Secondary stream 1:720×576(D1_PAL),720×480(D1_NTSC),352×288 (CIF_PAL),352×240(CIF_NTSC) |
| Video bit rate |
Only for H.264 and H.265 5MP:512kbit/s to 8Mbit/s; 4MP:512kbit/s to 8Mbit/s; 3MP:512kbit/s to 8Mbit/s; 1080P:512kbit/s to 8Mbit/s; 720P:256kbit/s to 4Mbit/s; D1:256kbit/s to 2Mbit/s; CIF:32kbit/s to 1Mbit/s |
| Digital noise reduction |
2D/3D noise reduction |
| Mini illumination |
Color: 0.02 Lux (F1.2, AGC ON, 1/30s shutter speed) B/W: 0.01Lux (f1.2, AGC ON, 1/30s shutter speed) |
| Audio encoding format |
G.711a/G.711u/G.726/AAC (default: G.711a) |
| Audio sampling rate |
G.711a/G.711u/G.726:8K AAC:8K/16K/22.05K/24K/32K/44.1K/48K |
| Audio bit rate |
G.711a/G.711u: 64 kbit/s G.726: configurable (16/24/32/40 kbit/s) AAC: 8 kHz sampling rate: 16/22/24/32/48 kbit/s 16 kHz sampling rate: 24/32/48/64/96 kbit/s 22.05/24/32 kHz sampling rate: 32/48/64 /96/128 kbit/s 44.1/48 kHz sampling rate: 48/64/96/128/256 kbit/s |
| Protocols supported by IPv4 |
TCP,UDP,IPv4,DHCP,DNS,ICMP,IGMP,HTTPS,FTP,SFTP,RTP,RTSP,RTCP,SIP,ARP,SSL,NTP,SNMP(V1/V2/V3),802.1x,QoS,SMTP |
| Protocols supported by IPv6 |
HTTPS,RTP,RTCP,RTSP,Onvif,IPv6,ICMPv6,DHCPv6 |
| Web Browser |
Google Chrome, Firefox, Edge |
| User rights |
Three user roles: administrator, advanced operator, and common operator |
| Security mode |
User name and password authentication, 802.1X authentication, and HTTPS digital certificate |
| Secure boot |
Supported |
| Alarm information |
HTTPS certificate expiration/SDK certificate expiration/SDK root certificate expiration/SDK revocation certificate expiration/802.1X certificate expiration/Network disconnection/Failure to write data to disks/Media stream interrupted/Flash read/write/Version rollback |
| Alarm port |
2 input port and 1 output port |
| Audio port |
Supported (one-channel LINE OUT)/Supported (one-channel built-in microphone) |
| Power type |
DC12V,PoE(IEEE 802.3af) |
| Power consumption |
Typical: 2.62W |
| Operating temperature |
-30℃ to 60℃ |
| Operating humidity |
5% to 95%(non-condensing) |
| Surge protection |
4kV |
| IP rating |
IP67 |
| Weight |
Net weight 574g; Gross weight 734g |
| Dimensions |
Device dimensions122*122*102mm; Package dimensions 142×140×112mm |
