Product Details
IE-2000U-4S-G
Original price was: $1,495.00.$877.00Current price is: $877.00.
| Model: | IE-2000U-4S-G – Cisco Industrial Ethernet 2000 Switches |
| Detail: | IE 2000U 4 SFP FE, 2 SFP GE ports |
Description
IE-2000U-4S-G – Cisco Industrial Ethernet 2000 Switches
Searching for a Cisco IE-2000U-4S-G Switch for productive systems administration at your working environment? Search no more! Our gntme.com site gives you the best cisco items that fulfill every one of your necessities.
Switches are the establishment of most business organizations, and how critical they are for your work environment. Through Cisco Switches, gadgets associated with your organization can speak with each other and furthermore with different organizations effectively, much the same as the Internet.
The Cisco 2000U Industrial Ethernet Switches (IE 2000U) are a scope of conservative switches intended for the brutal, rough conditions regularly found in the energy and utility enterprises. IE 2000U switches are intended to help the correspondences framework needs for the energy conveyance foundation across disseminated age, transmission, and dispersion areas. This framework incorporates utility and client claimed energy foundation, for example, substation applications supporting electrical transmission and dispersion, inexhaustible age, oil and gas, water, conveyed age, cogeneration, and trackside activities. The foundation additionally incorporates correspondence framework for conveyance applications like transmission pipelines, dispersion mains, and administration lines for oil and gas and water. Buy Related Product like IE-2000-16PTC-G-L.
Main Features :
- Switch
- managed
- 4 x 100 Mbit SFP + 2 x 1000Base-X SFP (uplink)
- DIN rail mountable
IE-2000U-4S-G Specification |
|
| General | |
| Device Type | Switch – 6 ports – managed |
| Enclosure Type | DIN rail mountable |
| Subtype | Gigabit Ethernet |
| Ports | 4 x 100 Mbit SFP + 2 x 1000Base-X SFP (uplink) |
| Performance | Forwarding performance (64-byte packet size): 6.5 Mpps |
| Capacity | Virtual interfaces (VLANs): 1000 ¦ IGMP groups: 1000 |
| MAC Address Table Size | 8K entries |
| Routing Protocol | OSPF, BGP-4, IS-IS, RIP-1, RIP-2, EIGRP, HSRP, IGMP, PIM-SM, PIM-DM, MLDv2, MLD |
| Remote Management Protocol | SNMP 1, SNMP 2, RMON 2, RMON, SNMP 3, HTTP, TFTP, SSH, CLI, SCP |
| Encryption Algorithm | SSL |
| Authentication Method | Secure Shell (SSH), RADIUS, TACACS+ |
| Features | ARP support, VLAN support, Syslog support, PIM snooping, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, DHCP snooping, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), Digital Optical Monitoring (DOM) support, Virtual Route Forwarding-Lite (VRF-Lite), MLD snooping, Dynamic ARP Inspection (DAI), Time Domain Reflectometry (TDR), Bidirectional Forwarding Detection (BFD), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Port Security, Remote Switch Port Analyzer (RSPAN), Hot Standby Router Protocol (HSRP) support, Management Information Base (MIB), rugged, Strict Priority Queuing (SPQ), Class of Service (CoS), 802.1x authentication, FTP client, Storm Control, Resilient Ethernet Protocol (REP), Parallel Redundancy Protocol (PRP) |
| Compliant Standards | IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at, IEEE 1588v2 |
| RAM | 256 MB |
| Flash Memory | 128 MB |
| Expansion / Connectivity | |
| Interfaces | 4 x 100Base-FX SFP downlink ¦ 2 x 1000Base-X SFP uplink ¦ 1 x console RJ-45 ¦ 1 x mini-USB Type B |
| Expansion Slots | 1 (total) / 1 (free) x SD Memory Card |
| Power | |
| Power Consumption Operational | 15 Watt |
| Miscellaneous | |
| Compliant Standards | CISPR 22 Class A, CISPR 24, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, EN55024, ICES-003 Class A, UL 508, FCC Part 15 A, CSA 22.2 No. 142, VCCI Class A, KN24, KN22 Class A, ANSI/ISA.12.12.01 Class I Division 2 Groups ABCD, IEC 61850-3, IEC/UL/CSA/EN 60950-1, EN 55022 Class A, EN 60079-15:2010, IEEE 1613, CNS 13438 Class A, EN 300 386 |
| Software / System Requirements | |
| Software Included | Cisco IOS LAN Base |
| Dimensions & Weight | |
| Width | 3.1 in |
| Depth | 4.5 in |
| Height | 5.1 in |
| Weight | 2.69 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty – advance parts replacement – 5 years – response time: 10 days |
| Environmental Parameters | |
| Min Operating Temperature | -40 °F |
| Max Operating Temperature | 158 °F |
| Humidity Range Operating | 5 – 95% (non-condensing) |
| Min Storage Temperature | -58 °F |
| Max Storage Temperature | 185 °F |
