Product Details
IE-2000-4TS-B
Original price was: AED1,295.00.AED760.00Current price is: AED760.00.
| Model: | IE-2000-4TS-B – Industrial Ethernet 2000 Series |
| Detail: | IE 4 10/100,2 FE SFP, Base |
PDF Attachment:
Description
ie-2000-4ts-b datasheet
IE-2000-4TS-B – Industrial Ethernet 2000 Series
ie-2000-4ts-b datasheet, Searching for an IE-2000-4TS-B Switch for productive systems administration at your working environment? Search no more! Our gntme.com site gives you the best cisco items that fulfill every one of your necessities.
The Cisco Industrial Ethernet 2000 (IE 2000) arrangement is a scope of smaller, modernly ruggedized admittance switches. IE 2000 arrangement furnishes clients effortlessly of utilization, secure access, and industry-driving intermingling utilizing Cisco Resilient Ethernet Protocol (REP). Various businesses like auto, oil and gas, mining, transportation, and energy organizations are all undeniably requiring IP-based organizations in their creation regions. The IE 2000 augmentations have been intended to help access layer availability and to meet the expanding needs for security, voice, and video traffic across mechanical organizations. Buy related product IE-2000-16PTC-G-E.
Main Features :
- Switch
- managed
- 4 x 10/100 + 2 x SFP
- DIN rail mountable
IE-2000-4TS-B Specification |
|
|
Physical Specification |
|
|
Total Ports |
6 |
|
RJ45 ports |
4 FE |
|
SFP ports |
2 FE |
|
Manufacturing license |
LAN Base |
|
Hardware |
● 256 MB DRAM with ECC memory ● IEEE 1588v2 FPGA ● 64 MB on-board flash memory ● 1GB removable SD flash memory card (optional) ● Mini-USB connector |
|
Alarm |
● Alarm I/O: Two alarm inputs to detect dry contact open or close; one alarm output relay |
|
Power consumption |
● 4-port downlink models: 9.5-15 W |
|
Connectors and cabling |
● 10/100/1000BASE-T ports: RJ-45 connectors, 4-pair Category 5 UTP cabling |
|
Dimensions including DIN rail |
● IE-2000 6 ports (copper downlinks) chassis: 5.1”H x 2.95”W x 4.51”D in (130mm H x 74.9mm W x 115mm D) |
|
Weight |
● IE-2000 6 ports chassis: 2.45 lb (1.11 kg) |
|
IE2000 Software Features |
|
|
LAN Lite license |
Baseline features |
|
Layer 2 switching |
IEEE 802.1, 802.3, 802.3at, 802.3af standard (see Table 8), VTPv2, NTP, UDLD, CDP, LLDP, Unicast MAC filter, Resilient Ethernet Protocol (REP), Media Redundancy Protocol (MRP) Ring (IEC 62439-2) |
|
Security |
SCP, SSH, SNMPv3, TACACS+, RADIUS Server/Client, MAC Address Notification, BPDU Guard, SPAN session |
|
Multicast |
IGMPv1, v2, v3 Snooping, IGMP filtering, IGMP Querier |
|
Management |
Fast Boot, Express Setup, Web Device Manager, CNA, Cisco Prime, LMS, MIB, SmartPort, SNMP, syslog |
|
Industrial Ethernet |
EtherNet/IP, Profinet v2 |
|
LAN Base license |
Additional features |
|
Layer 2 switching |
VTPv3, EtherChannel, Voice VLAN, Flexlink |
|
Security |
IPv4 Port-Security, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard, 802.1x, Guest VLAN. MAC Authentication Bypass, 802.1x Multi-Domain Authentication, Storm Control, Trust Boundary, Access-List (ACL) |
|
Quality of service |
IPv4 Ingress Policing, Rate-Limit, Egress Queuing/Shaping, AutoQoS, PROFINET QoS |
|
Management |
Port-Based DHCP, Storm Control – Unicast, Multicast, Broadcast, SPAN Sessions, RSPAN, DHCP Server, Customized TCAM/SDM Size Configuration, Embedded Event Manager (EEM) |
|
Industrial Ethernet |
IEEE 1588 PTPv2 |
|
IPv4 routing |
IPv4 static routing |
|
IPv6 routing |
IPv6 host support, HTTP over IPv6, SNMP over IPv6 |
|
Enhanced LAN Base |
Additional features |
|
Industrial management |
Layer 2 switching with 1:1 static Network Address Translation (NAT) |
|
IP Lite license |
Additional features |
|
IPv4 routing |
RIP, OSPF, EIGRP, VRF Lite, PIM for L3 multicast routing including sparse (SM) and dense (DM) mode. |
|
IPv6 Routing |
IPv6 Static routing, OSPFv3 |
|
Security |
FIPS 140-2 |
|
Embedded Event Manager |
EEM feature enabled with IP Lite license |
|
DNA Essentials |
Additional features |
|
Cisco DNA Center |
Discovery, topology, inventory, software image management |
|
Visibility |
DNA assurance, Device 360 |
|
Day-zero network bring-up automation |
Cisco Network Plug-and-Play application |
