| CPU |
32-bit multi-core high-performance processor |
| Memory |
16 GB (DDR3) |
| Video input |
32 channels, 320 Mbit/s access |
| Video forwarding |
320 Mbit/s |
| Playback/Download |
128 Mbit/s playback |
| Local decoding |
8MP (4K): 4-channel 30 fps; 4MP: 8-channel 30 fps; 2MP (1080p): 16-channel 30 fps |
| HDMI |
One HDMI 2.0 port; resolutions: 1024 x 768, 1280 x 720, 1280 x 1024, 1440 x 900, 1920 x 1080, 2560 x 1440, 3840 x 2160 |
| VGA |
One VGA port; resolutions: 1024 x 768, 1280 x 720, 1280 x 1024, 1440 x 900, 1920 x 1080 |
| Preview |
1/4/6/8/9/10/12/13/14/16/17/19/20/22/25/32 panes |
| Disks |
4 |
| Disk port |
SATA2.0 |
| Disk type |
4TB/6TB per port |
| Recording mode |
Manual recording, scheduled recording, motion detection-triggered recording, and recording triggered by I/O alarms |
| Recording playback |
16-channel simultaneous playback; controls: fast forward (2x, 4x, 8x, or 16x) and slow-down (1/16x, 1/8x, 1/4x, or 1/2x) |
| Search mode |
By time, recording type, or AI event |
| Download mode |
In batches or by segment |
| Video format |
H.264/H.265 |
| Audio format |
G.711a/G.711u |
| Network protocols |
TCP, UDP, RTP, RTSP, HTTP, DNS, NTP, SMTP, and DHCP |
| Device access |
HOLOWITS SDK and ONVIF |
| Web access |
Compatible with Internet Explorer 9, 10, and 11 |
| Management mode |
Web and LDU |
| Log type |
Log functions: operation logs, system logs, alarm logs, parameter modification logs, recording logs, intelligent log check, and log storage |
| Network port |
2 x RJ45 10M/100M/1000M adaptive Ethernet port |
| USB port |
3 x USB ports (one USB 2.0 port on the front panel; one USB 2.0 port and one USB 3.0 port on the rear panel) |
| Serial port |
1 x half-duplex RS-485 port |
| Audio input |
1 channel, RCA port |
| Audio output |
1 channel, RCA port |
| Alarm port |
16-channel alarm input, 1-channel alarm output |
| Operating temperature |
0°C to 45°C |
| Operating humidity |
20% to 90% |
| Power consumption |
≤ 7 W (without hard disk and PoE output) |
| Power supply |
12 V/6 A |
| Dimensions |
Equipment dimensions 66 mm (H) x 378 mm (W) x 326 mm (D) Package dimensions 115 mm (H) x 500 mm (W) x 375 mm (D) |
| Shelf |
19-inch standard 1.5 U shelf |
| Weight |
Net Weight 2.4 kg (excluding hard disks) Gross Weight 2.9kg (excluding hard disks) |
| Certification |
CE, RoHS, WEEE, CCC and CQC |
