| Computing power |
1 TOPS |
| CPU |
64-bit high-performance 8-core processor |
| Memory |
8 GB (DDR4 2400) |
| Image-based target analysis |
6 channels (1080p, 0.5 partial image/second/camera); 3 channels (4K, one partial image/second/camera) |
| Video-based target analysis |
2 channels (1080p, 60 images/minute/channel); 1 channel (4K, 60 images/minute/channel) |
| Video-based vehicle analysis |
2 channels (1080p, 60 vehicles/minute/channel); 1 channel (4K, 60 vehicles/minute/channel) |
| Video-based person analysis |
2 channels (1080p, 60 persons/minute/channel); 1 channel (4K, 60 persons/minute/channel) |
| Behavior analysis |
Perimeter detection: 2 channels (tripwire crossing detection, intrusion detection, area entry/exit detection, loitering detection, and fast movement detection) |
| Maximum number of target alert reference lists |
32 |
| Total capacity of target lists |
300,000 |
| Target hot data search |
< 3s |
| Target feature storage capacity |
5,000,000 |
| Personal feature cold data search |
< 10s |
| Maximum number of vehicle alert reference lists |
5 |
| Total capacity of vehicle lists |
50,000 |
| Structured data storage capacity |
Up to 1.2 million target records and 2 million vehicle records |
| Video access |
64 channels, 320 Mbit/s |
| Video forwarding |
64 channels, 320 Mbit/s |
| Playback/Download |
32 channels, 160 Mbit/s |
| Camera access |
A single device supports access of up to 64 cameras. |
| Client |
iClient (installed on a computer); A device supports access from up to two clients at the same time. |
| LDU login |
The LDU supports two screens. |
| Maximum number of registered users on the iClient |
32 |
| HDMI |
Two HDMI 2.0 ports |
| VGA |
External conversion cables can be used to extend VGA ports. |
| Preview |
Primary screen: 1/4/8/9/16/32/64 panes; secondary screen: 1/4/8/9/16 panes |
| Disk quantity |
8 |
| Disk port |
SATA 3.0 |
| Disk type |
Enterprise disks: 4 TB, 6 TB, 8 TB, or 16 TB |
| Disk type |
Surveillance disks: 6 TB |
| Disk type |
System storage: 32 GB eMMC |
| RAID level |
RAID 0, RAID 1, and RAID 5 |
| Recording mode |
Manual recording, scheduled recording, and alarm-triggered recording |
| Recording playback |
LDU: multi-channel simultaneous playback and segment-based playback |
| Recording playback |
iClient: single-channel playback and multi-channel simultaneous playback on the video wall |
| Recording protection |
SafeVideo, recording lock, and resumable upload |
| Recording query method |
By time or event |
| Recording download method |
High-speed download, batch download, download by time segment, and onboard recording download |
| Media security |
Multiple encryption algorithms such as AES256 are supported for data transmission. |
| Watermark |
Digital watermarks can be added to video from cameras. Alarms are generated when video is tampered with. |
| Media transmission |
Adaptive bandwidth, forward error correction (FEC) 1.0, super error concealment (SEC) 2.0, and multicast |
| Data Safe |
Two copies of key system data are stored. If a fault occurs, service data can be automatically restored. |
| Video format |
H.264, H.265, and MJPEG |
| Device access |
HOLOWITS SDK, GB/T 28181, and ONVIF standards |
| Network protocol |
TCP, UDP, RTP, RTSP, RTCP, HTTP, SNMP, NTP, SMTP, DHCP, SSH, SFTP, FTP,andRTSP |
| Platform access |
Connected to the platform through GB/T 28181, ONVIF, or GA/T 1400 for servicessuchaslive video viewing, recording playback, PTZ control, and alarmreporting (FunctionsonlyasanNVR) |
| Management mode |
Local display unit (LDU) or client/server (C/S) (iClient S100/iClient S200) |
| Log download |
Operation and run logs |
| Network port |
2 x GE electrical ports, support for the load balancing and multi-address modes |
| USB port |
3 x USB ports (2 x USB 2.0 ports on the front panel and 1 x USB 3.0 port on the rear panel) |
| Audio input |
One RCA port |
| Audio output |
One RCA port |
| Alarm port |
16 alarm-in ports and 4 alarm-out ports |
| Environment requirements |
Operating temperature: -10℃ to +50℃ Operating humidity: 20% to 90% |
| Power supply |
200–240 V AC, 200 W |
| Power consumption (including disks |
124 W |
| Fan |
Intelligent speed control |
| Product dimensions (H x W x D) |
86.1 mm x 447 mm x 470 mm |
| Chassis |
2 U |
| Weight (without disks) |
6.6 kg |
| Certification |
CE and HDMI |
