| Compute power |
20 TOPS |
| Memory |
12 GB DDR4 |
| Image-based target analysis |
48 channels (1080p, 0.5 partial image/second/camera) 24 channels (4K, one partial image/second/camera) |
| Video-based target analysis |
8 channels (1080p, 30 images/minute/channel) 2 channel (4K, 60 images/minute/channel) |
| Video-based vehicle analysis |
8 channels (1080p, 30 images/minute/channel) 2 channel (4K, 60 images/minute/channel) |
| Behavior analysis |
Perimeter detection: 8 channels (tripwire crossing detection, intrusion detection, area entry/exit detection, loitering detection, and fast movement detection) |
| Number of target alert reference lists |
32 |
| Total target library capacity |
300,000 records |
| Target hot data search |
< 3s |
| Target feature storage |
5 million records |
| Personal feature cold data search |
< 10s |
| Number of vehicle alert reference lists |
5 |
| Total vehicle library capacity |
50,000 records |
| Structured data storage |
Up to 1.2 million person records and 2 million vehicle records |
| Video input |
128-channel access at 512 Mbit/s |
| Video storage |
128-channel access at 512 Mbit/s |
| Video forwarding |
128-channel forwarding at 512 Mbit/s(320 Mbit/s storage with intelligent services enabled) |
| Playback and download |
32-channel playback at 160 Mbit/s |
| Camera access |
128 cameras connected to one server |
| Client |
iClient (installed on PCs), managing up to 16 servers |
| Local system login |
The LDU supports only one user at a time. |
| iClient login |
Supports 32 users. |
| HDMI |
2 HDMI ports |
| VGA |
External conversion cables can be used to extend VGA ports. |
| Preview |
Primary screen: 1/4/8/9/16/32/64 panes; secondary screen: 1/4/8/9/16 panes |
| Number of disks |
16 |
| Disk port |
SATA 3.0 |
| Disk type |
Enterprise-level disks: 4 TB, 6 TB, 8 TB, 10 or 16 TB Monitoring-level disks: 6 TB System storage: 32 GB eMMC |
| RAID level |
RAID 0, RAID 1, and RAID 5 |
