HWT-DEC810

Network Matrix with 10ch HDMI output

Support network media input
Support multiple resolution of output, it can manually set output resolution
HDMI input support maximum 4K resolution
Output supports maximum 3840×2160@30Hz
Can decode video of 8K, 4K, 1080P, 1080I, 720P, D1
H265/H264 compatible
Every HDMI ouput port support 2ch 4K or 8ch 1080P or 16ch 720P decoding and display
Support video-splitting output, up to 64 windows split on one monitor

Categories: Display & Control, HOLOWITS

HDMI Input	no physical HDMI input
HDMI Output	10ch HDMI output
Ethernet	100M/1000M self adaptive
Audio input	no physical audio input
Audio output	10ch，by Ф3.5 audio interface
Alarm output	support network alarm input
USB2.0	none
RS232/422/485	1
Network video decoding	H.265,H.264
Network video input	4K, 1080P,1080I,720P,D1
HDMI ouput resolution	1024×768P@60hz,1280×720P@60hz,1366×768P@60hz,1920×1080P@60hz,3840×2160@30hz
Video decode and display	every hdmi can decode 2ch 4K or 8ch 1080P or 16ch 720P or 32ch D1
Monitor splicing	10 monitor to splice and display one video
Split	maximum 64 split,1/4/6/8/9/10/16/25/36/64 splitting mode and display，or split by user-define
OSD	Window, Channel,label, alarm, etc. information
Audio Codec	G.711,G.726,ADPCM encode/decode
On/Mute	Supports all channels and single channel set individually
Audio output	10ch, by Ф3.5 audio interface
Power supply	AC100 to 230V
