- Description
Description
Huawei s5731-s48p4x s5700 Series Switch
Overview of Huawei s5731-s48p4x s5700 Series Switch
The switch offers a range of standard gigabit access with all-GE electrical/optical ports and fixed 10 GE uplink ports. Built on Huawei’s unified Versatile Routing Platform (VRP), Huawei S5731-S48P4X Switch provide enhanced Layer 3 features, simplified Operations & Maintenance (O&M), Intelligent Stack (iStack) technology. This allows multiple stacking-capable switches to function as a single logical switch. It is widely used in a range of scenarios, including enterprise campus access and aggregation, as well as data center access
Huawei CloudEngine S5731-S48P4X switch with 48-ports 4x10GE SFP+
With 1+1 power backup, PoE+
Forwarding performance: 125 Mpps, Switching capacity: 176 Gbps/672 Gbps
The CloudEngine S5731-S series switches were developed based on next-generation high-performing hardware and the Huawei Versatile Routing Platform (VRP). The CloudEngine S5731-S supports simplified operations and maintenance (O&M), intelligent stack (iStack), flexible Ethernet networking. It also provides enhanced Layer 3 features and mature IPv6 features.
The CloudEngine S5731-S can be used in various scenarios. For example, it can be used as an access or aggregation switch on a campus network or as an access switch for Metropolitan Area Network.
Specification of Huawei s5731-s48p4x s5700 Series Switch
| Fixed Port | 48 x 10/100/1000Base-T (PoE+) ports, 4 x 10GE SFP+ ports | |
| Power supply type | 1000 W PoE AC (pluggable) | |
| Rated voltage range | AC input (1000 W AC PoE): 100 V AC to 240 V AC, 50/60 Hz | |
| Maximum voltage range | AC input (1000 W AC PoE): 90 V AC to 290 V AC, 45 Hz to 65 Hz
High-voltage DC input (1000 W AC PoE): 190 V DC to 290 V DC (meeting 240 V high-voltage DC certification) |
|
| Maximum power consumption | 132 W (without PD) 1750 W (with PD, PD power consumption of 1440 W) | |
| Noise | Under normal temperature (sound power): 62.3dB (A)
Under high temperature (sound power): 71.8dB (A) Under normal temperature (sound pressure): 52.8dB (A) |
|
| Operating temperature | 0-1800 m altitude: -5°C to +45°C
1800-5000 m altitude: The operating temperature reduces by 1ºC every time the altitude increases by 220 m. |
|
| Storage temperature | -40℃ to +70℃ | |
| Relative humidity | 5% to 95% (non condensing) | |
| Surge protection specification (service port) | Common mode: ±6 kV | |
| Surge protection specification (power port) | Differential mode: ±6 kV; Common mode: ±6 kV | |
| Heat dissipation | Air cooling heat dissipation, intelligent speed adjustment, and pluggable fans | |
| Dimensions (H x W xD) | 442 mm x 420 mm x 43.6 mm | |
| Chassis height | 1 U | |
| Chassis weight (including packaging) | 8.8 kg | |
Features of Huawei s5731-s48p4x s5700 Series Switch
- Support many Layer 2/Layer 3 multicast protocols such as PIM SM, PIM DM, PIM SSM, MLD, and IGMP snooping, to support multi-terminal high-definition video backhaul and video conferencing services.
- Support multiple Layer 3 features including OSPF, IS-IS, BGP, and VRRP, meeting enterprises’ requirements on access and aggregation service bearing, and enabling a variety of voice, video, and data applications.
- Support MAC address authentication, 802. 1x authentication, and Portal authentication, and implements dynamic delivery of policies (VLAN, QoS, and ACL) to users.
- Provide a series of mechanisms to defend against DoS and user-targeted attacks. DoS attacks are targeted at switches and include SYN flood, Land, Smurf, and ICMP flood attacks. User-targeted attacks include bogus DHCP server attacks, IP/MAC address spoofing, DHCP request flood, and change of the DHCP CHADDR value.
For more information about this switch ,visit the Huawei Website.
Visit Our Website for the best quality products with the best price.
