Fortinet FortiSwitch 148F‑FPOE – 48‑Port PoE+ Managed Switch with 4×10G SFP+ & 740 W PoE Budget
The FortiSwitch 148F‑FPOE is a 1 U managed PoE+ switch with 48 Gigabit access ports and 4×10 GbE SFP+ uplinks, offering up to 740 W PoE power and strong Layer 2 performance for enterprise access networks.
- Description
Description
The Fortinet FortiSwitch 148F‑FPOE is a high‑capacity, enterprise‑ready managed Layer 2 Ethernet switch designed to deliver both robust network connectivity and Power over Ethernet (PoE) for demanding access networks. It features 48 × 1 GbE RJ‑45 ports with full PoE+ support and 4×10 GbE SFP+ uplink ports, making it suitable for powering large numbers of PoE devices (such as wireless access points, VoIP phones, and surveillance cameras) while maintaining high throughput and scalability.
This rack‑mountable 1 U switch supports a maximum PoE power budget of up to 740 W (48 ports compliant with IEEE 802.3af/at standards), allowing all access ports to deliver power simultaneously for PoE endpoints. It delivers a 176 Gbps switching capacity and up to 260 Mpps throughput, ensuring efficient traffic handling across VLANs, link aggregation groups, and access control lists in medium‑to‑large network deployments. Tight integration with Fortinet’s FortiLink management and Security Fabric enables centralized control and visibility via FortiGate appliances.
Key Features:
-
48 × Gigabit RJ‑45 PoE+ ports with up to 740 W PoE budget to power network devices directly over Ethernet
-
4 × 10 GbE SFP+ uplink ports for high‑speed fiber connectivity to aggregation/core switches
-
176 Gbps switching capacity with 260 Mpps throughput for smooth traffic flow
-
Support for VLANs, link aggregation (LACP), spanning tree, and ACLs for flexible Layer 2 network segmentation
-
Integrated FortiLink support for management from FortiGate and Fortinet Security Fabric integration
