Description
The Fortinet FortiGate 500E Firewall is an enterprise-grade next-generation firewall (NGFW) designed to deliver advanced security, high-speed performance, and reliable network protection. In addition, it combines threat prevention, application control, and secure connectivity in a single platform. As a result, organizations can protect critical business operations while maintaining network efficiency.
Furthermore, the Fortinet FortiGate 500E Firewall provides centralized security management and deep network visibility to help businesses strengthen cybersecurity and improve operational control.
Additionally, it supports scalable enterprise deployments, making it a suitable solution for organizations with growing networking and security requirements.
Key Features
- Moreover, it combines next-generation firewall protection with advanced threat prevention.
- In addition, integrated security services help detect and block sophisticated cyber threats.
- Furthermore, deep network visibility improves traffic monitoring and management.
- It also supports secure VPN connectivity for branch offices and remote users.
- Additionally, application control and web filtering enhance network security.
- As a result, organizations can protect critical assets without compromising performance.
- Furthermore, centralized management simplifies policy enforcement and administration.
- Finally, optional FortiCare and FortiGuard services provide enhanced support and threat intelligence.
FG-500E Specification |
| Type | FORTIGATE 500E |
Interfaces and Modules |
| 10 GE SFP+ Slots | 2 |
| GE SFP Slots | 8 |
| GE RJ45 Interfaces | 8 |
| GE RJ45 Management Ports | 2 |
| USB Ports | 2 |
| RJ45 Console Port | 1 |
| Local Storage | NIL |
| Included Transceivers | 2x SFP (SX 1 GE) |
System Performance and Capacity |
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) | 36 / 36 / 22 Gbps |
| IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP) | 36 / 36 / 22 Gbps |
| Firewall Latency (64 byte, UDP) | 2 μs |
| Firewall Throughput (Packet per Second) | 33 Mpps |
| Concurrent Sessions (TCP) | 8 Million |
| New Sessions/Second (TCP) | 300,000 |
| Firewall Policies | 10,000 |
| IPsec VPN Throughput (512 byte) | 5 Gbps |
| Client-to-Gateway IPsec VPN Tunnels | 50,000 |
| SSL-VPN Throughput | 5 Gbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 10,000 |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 5.7 Gbps |
| SSL Inspection CPS (IPS, avg. HTTPS) | 3,500 |
| Application Control Throughput (HTTP 64K) | 14 Gbps |
| CAPWAP Throughput (1444 byte, UDP) | 18 Gbps |
| Virtual Domains (Default / Maximum) | 10 / 10 |
| Maximum Number of FortiSwitches Supported | 48 |
| Maximum Number of FortiAPs (Total / Tunnel) | 512 / 256 |
| Maximum Number of FortiTokens | 5,000 |
| Maximum Number of Registered FortiClients | 2,000 |
| High Availability Configurations | Active-Active, Active-Passive, Clustering |
System Performance — Enterprise Traffic Mix |
| IPS Throughput | 5.2 Gbps |
| NGFW Throughput | 5 Gbps |
| Threat Protection Throughput | 4.7 Gbps |
Dimensions and Power |
| Height x Width x Length | 1.75 x 17.0 x 15.0 inches 44.45 x 432 x 380 mm |
| Form Factor | 1 RU |
| AC Power Supply | 100–240V AC, 60–50 Hz |
| Power Consumption (Average / Maximum) | 95 W / 193 W |
| Current (Maximum) | 6A |
| Heat Dissipation | 613 BTU/h |
| Redundant Power Supplies | optional |
Operating Environment and Certifications |
| Operating Temperature | 32–104°F (0–40°C) |
| Storage Temperature | -31–158°F (-35–70°C) |
| Humidity | 10–90% non-condensing |
| Noise Level | 43 dBA |
| Operating Altitude | Up to 7,400 ft (2,250 m) |
| Compliance | FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB |
| Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6 |
