Product Details
FG-3000D
| Model: | FG-3000D – Fortinet NGFW High-end Series FortiGate 3000D |
| Detail: | Fortinet FG-3000D 16 x 10GE SFP+ slots, 2 x GE RJ45 Management, SPU NP6 and CP8 hardware accelerated, 480GB SSD onboard storage, and dual AC power supplies |
Description
FG-3000D Specification |
|
|
Type |
FORTIGATE 3000D |
|
Interfaces and Modules |
|
|
10 GE SFP+ / GE SFP Slots |
16 |
|
GE RJ45 Management Ports |
2 |
|
USB Ports (Server) |
1 |
|
Console Port |
1 |
|
Internal Storage |
1x 480 GB SSD |
|
Included Transceivers |
2x SFP+ (SR 10GE) |
|
System Performance and Capacity |
|
|
Firewall Throughput (1518 / 512 / 64 byte, UDP) |
80 / 80 / 50 Gbps |
|
IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP) |
80 / 80 / 50 Gbps |
|
Firewall Latency (64 byte, UDP) |
3 µs |
|
Firewall Throughput (Packet per Second) |
75 Mpps |
|
Concurrent Sessions (TCP) |
50 Million |
|
New Sessions/Second (TCP) |
400,000 |
|
Firewall Policies |
200,000 |
|
IPsec VPN Throughput (512 byte) |
50 Gbps |
|
Gateway-to-Gateway IPsec VPN Tunnels |
40,000 |
|
Client-to-Gateway IPsec VPN Tunnels |
200,000 |
|
SSL-VPN Throughput |
8 Gbps |
|
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) |
30,000 |
|
SSL Inspection Throughput (IPS, avg. HTTPS) |
15 Gbps |
|
SSL Inspection CPS (IPS, avg. HTTPS) |
8,000 |
|
Application Control Throughput (HTTP 64K) |
40 Gbps |
|
CAPWAP Throughput (1444 byte, UDP) |
22 Gbps |
|
Virtual Domains (Default / Maximum) |
10 / 500 |
|
Maximum Number of FortiSwitches Supported |
256 |
|
Maximum Number of FortiAPs (Total / Tunnel) |
4,096 / 1,024 |
|
Maximum Number of FortiTokens |
20,000 |
|
Maximum Number of Registered FortiClients |
50,000 |
|
High Availability Configurations |
Active / Active, Active / Passive, Clustering |
|
System Performance — Enterprise Traffic Mix |
|
|
IPS Throughput |
23 Gbps |
|
NGFW Throughput |
22 Gbps |
|
Threat Protection Throughput |
13 Gbps |
|
Dimensions and Power |
|
|
Height x Width x Length |
3.5 x 17.4 x 21.9 inches 88 x 442 x 555 mm |
|
Form Factor |
2 RU |
|
AC Power Supply |
100–240V AC, 50–60 Hz |
|
Power Consumption (Average / Maximum) |
310 W / 427 W |
|
Heat Dissipation |
1457 BTU/h |
|
Redundant Power Supplies |
Yes, Hot Swappable |
|
Operating Environment and Certifications |
|
|
Operating Temperature |
32–104°F (0–40°C) |
|
Storage Temperature |
-31–158°F (-35–70°C) |
|
Humidity |
10–90% non-condensing |
|
Noise Level |
50 dBA |
|
Operating Altitude |
Up to 7,400 ft (2,250 m) |
|
Compliance |
FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB |
|
Certifications |
ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6 |
