EG8143A5
EG8143A5 GPON Terminal with 1*GE+3*FE+1*POTS+1*CATV+WiFi, 5dBi
- Description
Description
| Specification | |
| Working environment | Operating temperature: 0ºC to 40ºC |
| Environment humidity: 5% to 95% (noncondensing) | |
| Static power consumption | 8.2 W |
| Power specifications | Power adapter input: 100 to 240 V AC, 50–60 Hz |
| System power supply: 12V, 1 A | |
| Network-side Port | GPON |
| User-side Ports | 1xGE+3xFE+1xPOTS+1xUSB+CATV+WIFI |
| Indicators | POWER/PON/LOS/LAN/TEL/WLAN/WPS/CATV |
| Dimensions(length x width x height) | 17.5*11.5*3.4cm |
| Weight | About 0.3kg |
| Surge Protection | E port: common mode 4 kV; differential mode 0.5 kV AC power supply: common mode 6 kV; differential mode 6 kV |
| GPON Port | Connector: SC/UPC Class B+ Receiver sensitivity: –27 dBm Overload optical power: –8 dBm Type B single-homing Type B dual-homing (supported in Layer 2 forwarding) |
| Ethernet Electrical Port | Ethernet port-based VLAN tags and tag removal 1:1 VLAN, N:1 VLAN, or VLAN transmission QinQ VLAN Limit on the number of learned MAC addresses MAC address learning |
| WLAN | IEEE 802.11 b/g/n (2.4G) 2 x 2 MIMO Antenna gain: 5Â dBi WMM Multiple SSIDs WPS Air interface rate: 300 Mbit/s |
| CATV Port | Frequency Range 54 MHz to 870 MHz Output resistance 75 ohms Received average optical power: -12dBm to +4dBm RF output power: ≥17dBmV/Ch |
| USBÂ Port | USB2.0 FTP-based network storage File/Print sharing based on SAMBA DLNA function |
