| Pixel Pitch |
0.9375 |
| LED Type |
Fully flip chip COB |
| Pixel Density |
1,137,777pixels /m² |
| Pixels Per Panel |
640×360 pixels |
| Module Size |
150mm×168.75mm |
| Panel Size |
600mm×337.5mm×29.8mm |
| Weight |
4kg/panel |
| Maintenance |
Front |
| Ingress Protection |
Rear IP50 |
| Curve |
/ |
| Panel Diagonal |
27” |
| Aspect Ratio |
16:9 |
| Panel Area |
0.2025m² |
| Recommended Viewing Distance |
≥0.9m |
| Environment |
Indoor |
| Material |
Die-cast Aluminum |
| Calibration |
Supports brightness and chroma |
| Brightness Control |
Manual/Automatic |
| Color Temperature |
2,000K-9,500K Adjustable |
| Viewing Angel |
0° ~180° |
| Brightness |
600cd/m² / 800cd/m² |
| Contrast Ratio |
10000：1 / 12000：1 |
| Input Power <Max> |
≤52 W/panel ; 260W/㎡ / ≤60 W/panel ; 300W/㎡ |
| Input Power <Typical> |
≤30 W/panel ; 150W/㎡ / ≤33 W/panel ; 165W/㎡ |
| Input Voltage |
100~240 V（ 50&60Hz） |
| Processing Depth |
19bit |
| Refresh Rate |
3840 Hz |
| Video Frame Rate |
50/60Hz |
| Input Power Frequency |
50&60 Hz |
| LED Life Time |
100,000 Hours |
| Operating Temperature/Humidity |
-10℃ ~+45℃/ 10~80% RH |
| Storage Temperature/Humidity |
-40℃ -+60℃/10~90% RH |
| Power Status |
Diagnostic LEDs |
| Standard Mounting Configuration |
Fixed |
| Certification |
CE |
