Dell PowerEdge T130 Xeon E3-1220 v5 32GB 2TB SATA Tower Server

Dell PowerEdge T130 Xeon E3-1220 V5 32GB 2TB SATA Tower Server Specification

Product Series

Dell PowerEdge T130 Server

Model

Dell PowerEdge T130 Xeon E3-1220 v5 32GB 2TB SATA Tower Server

Customizable

Intel® Xeon® E3-1220 v5, Windows Server® 2012 Foundation, 32GB Memory, 2TB Hard Drive, SATA and a 3 Year ProSupport Plus Warranty

Processor

Intel® Xeon® E3-1220 v5 3.0GHz, 8M cache, 4C/4T, turbo (80W)

Operating System

Windows Server® 2012R2,Foundation Ed,Factory Install,No MED

Memory

16GB (1x16GB) 2400MT/s DDR4 ECC UDIMM

Hard Drive

2TB 7.2K RPM SATA 6Gbps 3.5in Cabled Hard Drive

Warranty

3 Years ProSupport Plus Next Business Day On-site Service

Chipset

Intel C236

Embedded Hypervisor (Optional)

Hypervisor Support
Microsoft Windows Server with Hyper-V®
VMware® vSphere® ESXi®

Storage

3.5” Enterprise SATA 7.2K HDDs
3.5” nearline SAS 7.2K HDDs
3.5” 7.2K SATA entry drives

Drive Bays

4 x 3.5” cabled HDDs

RAID Controllers

S130,H330,H730, H830

Network Controller

Broadcom® BCM5720

Communications

2 X 1GbE LOM

Power

290W cabled PSU

Chassis

Mini tower

Device Access

8 total USB:
Rear USB: 2 x USB 3.0 plus 4 x USB 2.0
Front USB: 1 x USB 2.0 plus 1 x USB 3.0

Management

IPMI 2.0 compliant
Dell OpenManage Essentials
Dell OpenManage Mobile
Dell OpenManage Power Center

Dell OpenManage Integrations:
Dell OpenManage Integration Suite for Microsoft System Center
Dell OpenManage Integration for VMware vCenter®

Dell OpenManage Connections:
HP Operations Manager
IBM Tivoli® Netcool®
CA Network and Systems Management
Dell OpenManage Plug-in for Oracle® Database Manager

Remote management:
iDRAC8 with Lifecycle Controller
iDRAC8 Express (default)
iDRAC8 Enterprise (upgrade)
8GB vFlash media (upgrade)
16GB vFlash media (upgrade)

Dimensions

Height: 14.17 in / 36.0 cm
Width: 6.89 in / 17.5 cm
Depth: 17.12 in / 43.5 cm
