| Processing capability |
Supports 4K@60fps input/output encoding/decoding with backward compatibility, 4×4K@60 or 16×1080P@60 decoding |
| Codec capability |
Supports H.264/H.265 video encoding and PCM audio lossless transmission |
| Video port |
2×HDMI IN, 1×HDMI OUT, 1×DP OUT |
| Audio port |
1×3.5mm stereo input, 1×3.5mm stereo output, input sensitivity: 775mV |
| USB port |
2×USB2.0 (KVM), 2×USB3.0 (AV input), 1×Type-C |
| Network port |
1×RJ45, 10/100/1000Base-T, supports POE |
| OPTICAL port |
1×SFP |
| Serial port |
1×RS-485, 2×RS-232 |
| Infrared port |
1×IR IN, 4×IR OUT |
| I/O port |
3×I/O ports |
| Weak relay port |
2×RELAY ports |
| Reset button |
1×pinhole RESET button |
| Mode switch |
1×Input/output mode switch |
| Display screen |
2.23-inch OLED, 128×32 pixels |
| Power supply |
DC 12V / POE |
| Max power consumption |
10W |
| Ambient temperature |
-10°C~45°C (working), -15°C~45°C (non-working) |
| Ambient humidity |
5%~90% (working), no condensation |
| Weight |
About 1.0kg |
| Dimensions (L×W×H) |
240×117×41.8mm |
