Product Details
CPAK-100GE-LR4
AED42,000.00
| Model: | CPAK-100GE-LR4= – Cisco 100 Gigabit Optical Modules |
| Detail: | CPAK optical transceiver module, 100GBASE-LR4, 10km, no OTN |
Description
The Cisco CPAK 100GBASE modules offer clients a wide assortment of high-thickness 100Gbps availability answers for server farm organizing, elite figuring organizations, undertaking center total, and specialist co-op transport applications.
Cisco CPAK® 100GBASE fiber modules for Cisco® switches and switches offer a determination of high-thickness 100-Gbps availability arrangements. The modules are particularly appropriate for associations in big business and specialist organization server farms and in specialist organization edge organizations.
Main Features
100 Gigabit Ethernet
100GBase-LR4
LC single-mode
up to 6.2 miles
1310 nm
for P/N: A99-8X100GE-CM-RF
A9K-4X100GE-SE-RF
NC6-20X100GE-M-C
NC6-20X100GE-M-C=
CPAK-100GE-LR4= Specification |
|
| Description | 100GBASE-LR4 Cisco CPAK Module for SMF (terminated with LC Connectors) |
| Dimensions | 11.6 x 34.8 x 101.2 mm (0.46 x 1.37 x 3.98 in) |
|
Cisco CPAK port cabling specifications |
|
| Wavelength (nm) | 1310 |
| Cable Type | SMF Duplex |
| Core Size (Microns) | 9-micron core SMF per G.652 |
| Modal Bandwidth (MHz*km) | |
| Cable Distance | 10 km |
|
Optical transmit and receive specifications |
|
| Type | 100GBASE-LR4 1310 nm SMF |
| Transmit Power | Max:+4.5 per lane
Min:-4.3 per lane |
| Receive Power (dBm) | Max:+4.5 per lane
Min:-10.6 per lane |
| Transmit and Receive Center Wavelength Range (nm) | Four lanes:
1294.53 to 1296.59 1299.02 to 1301.09 1303.54 to 1305.63 1308.09 to 1310.19 |
| Supported Mode | 1x100G |
| Supported Protocol | IEEE 802.3ba |
|
Environmental conditions and power requirements |
|
| Storage temperature | -40 to 85° C (-40 to 185° F) |
| Operating temperature | 0 to 70° C (32 to 158° F) |
| Power consumption | At 70° C: <8.0 W maximum |
