| CISCO1841-SHDSL-V3 data sheet |
|---|
| Product Type | Router |
| Form Factor | Desktop – modular – 1U |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet |
| Network / Transport Protocol | IPSec |
| Remote Management Protocol | SNMP |
| Encryption Algorithm | DES, Triple DES, AES |
| Features | Firewall protection, 128-bit encryption, hardware encryption, VPN support, URL filtering, 256-bit encryption |
| DRAM Memory | 128 MB (installed) / 384 MB (max) – SDRAM |
| Flash Memory | 32 MB (installed) / 128 MB (max) |
| Communications |
|---|
| Type | DSL modem |
| Digital Signaling Protocol | SHDSL |
| Protocols & Specifications | ITU G.991.2 (G.shdsl) |
| Max Transfer Rate | 4.6 Mbps |
| IP Telephony |
|---|
| Voice Codecs | G.723, G.728, G.729, G.729a, G.726 |
| Connectivity Slots |
|---|
| Interfaces | 2 x 10Base-T/100Base-TX – RJ-45
Management : 1 x console – RJ-45
Serial : 1 x auxiliary – RJ-45
WAN : 1 x SHDSL |
| Expansion Slot(s) | 1 (total) / 1 (free) x AIM
2 (total) / 1 (free) x HWIC
Memory
1 CompactFlash Card |
| Power |
|---|
| Power Device | Power supply – internal – 50 Watt |
| Voltage Required | AC 120/230 V ( 50/60 Hz ) |
| Dimensions / Weight /Miscellaneous |
|---|
| Width | 34.3 cm |
| Depth | 27.4 cm |
| Height | 4.8 cm |
| Weight | 2.7 kg |
| Compliant Standards | CSA, CTR 21, CISPR 22 Class A, CISPR 24, EN 60950, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, UL 60950, EN50082-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CS-03, EN 61000-4-5 |
| Software Software |
|---|
| OS Provided | Cisco IOS |
| Software Included | CISCO IOS BROADBAND ROUTER |
