Product Details
Cisco CISCO3925/K9 Router
$3,877.00
| Model: | CISCO3925/K9 Cisco 3925 Router 3900 Series ISR G2 |
| Detail: | Cisco 3925 Router w/SPE100(3GE,4EHWIC,4DSP,2SM,256MBCF,1GBDRAM,IPB) |
Description
CISCO3925/K9 Specification |
||
| General | ||
| Manufacturer | Cisco Systems, Inc | |
| Manufacturer Part Number | CISCO3925/K9 | |
| Product Type | Router | |
| Form Factor | Desktop – modular – 3U | |
| Connectivity Technology | Wired | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet | |
| Capacity | Cisco Unified Communications Manager Express sessions : 250 Cisco Unified SRST sessions : 730 | |
| Network / Transport Protocol | IPSec, PPPoE, L2TPv3 | |
| Routing Protocol | OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing, policy-based
routing (PBR) |
|
| Remote Management Protocol | SNMP, RMON | |
| Encryption Algorithm | SSL | |
| Features | Firewall protection, VPN support, MPLS support, Syslog support, content filtering, IPv6 support, Class-Based Weighted Fair Queuing
(CBWFQ), Weighted Random Early Detection (WRED), Quality of Service (QoS), Dynamic Multipoint VPN (DMVPN) |
|
| Compliant Standards | IEEE 802.3, IEEE 802.1Q, IEEE 802.1ah, IEEE 802.1ag | |
| DRAM Memory | 1 GB (installed) / 2 GB (max) | |
| Flash Memory | 256 MB (installed) / 8 GB (max) | |
| LED Status Lights Indicators | Link activity, power | |
| Connectivity Slots | ||
| Router Interfaces | 3 x 10Base-T/100Base-TX/1000Base-T – RJ-45 Management : 1 x console – RJ-45 Management : 1 x console – mini-USB Type B Serial : 1 x auxiliary – RJ-45 Hi-Speed USB : 2 x 4 PIN USB Type A 2 x SFP (mini-GBIC) |
|
| Expansion Slots Total (Free) | 4 ( 4 ) x EHWIC 4 ( 4 ) x PVDM 2 ( 1 ) x CompactFlash Card 1 ( 1 ) x Expansion Slot 2 ( 2 ) x service module (SM) |
|
| Power Supply | ||
| Power Device | Power supply – internal | |
| Voltage Required | AC 120/230 V ( 47/63 Hz ) | |
| Dimensions / Weight / Miscellaneous | ||
| Dimensions (W × D × H) | 18.74 × 17.24 × 5.24 in (47.6 × 43.8 × 13.3 cm) | |
| Package Wight | 61.3 lbs (27.78 Kg) | |
| Weight | 39 lbs (17.7 kg) | |
| Compliant Standards | CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, AS/NZ 3548 Class A,
CAN/CSA-E60065-00, ICES- 003 Class A, CS-03, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60065, BSMI CNS 13438 |
|
| System Software | ||
| IOS Software Included | Cisco IOS IP Base | |
