Product Details
CE12812D-B00
$52,661.00
Model: | CE12812D-B00 Huawei CE12800 Series Data Center Switch |
Detail: | CE12812 DC Bundle0 (DC Assembly Chassis,2*MPUA,3*SFU12A,6*PDC-2200WA) |
Description
CE12812D-B00 Specifications |
|
Switching Capacity (Tbit/s) |
134/ 774 |
Forwarding Rate (Mpps) |
51,840 |
Service Slots | 12 |
Switching Fabric Module Slots |
6 |
Fabric Architecture | Clos architecture, cell switching, VoQ, and distributed large buffer |
Airflow Design | Strict front-to-back |
Device Virtualization | Virtual System (VS) |
Cluster Switch System (CSS)2 | |
Super Virtual Fabric (SVF)3 | |
Network Virtualization | M-LAG |
TRILL | |
VxLAN routing and bridging | |
EVPN | |
QinQ in VXLAN | |
VM Awareness | Agile Controller |
Network Convergence | FCoE |
DCBX, PFC, and ETS | |
Data Center Interconnect | BGP-EVPN |
Ethernet Virtual Network (EVN) for inter-DC Layer 2 network interconnections | |
Programmability | OpenFlow |
ENP programming | |
OPS programming | |
Puppet, Ansible, and OVSDB plug-ins released on open source websites | |
Linux container for open source and customization programming | |
Traffic Analysis | NetStream |
Hardware-based sFlow | |
VLAN | Adding access, trunk, and hybrid interfaces to VLANs |
Default VLAN | |
QinQ | |
MUX VLAN | |
GVRP | |
MAC Address | Dynamic learning and aging of MAC addresses |
Static, dynamic, and blackhole MAC address entries | |
Packet filtering based on source MAC addresses | |
MAC address limiting based on ports and VLANs | |
IP Routing | IPv4 routing protocols, such as RIP, OSPF, IS-IS, and BGP |
IPv6 routing protocols, such as RIPng, OSPFv3, ISISv6, and BGP4+ | |
IP packet fragmentation and reassembling | |
IPv6 | IPv6 over VXLAN |
IPv6 over IPv4 | |
IPv6 Neighbor Discovery (ND) | |
Path MTU Discovery (PMTU) | |
TCP6, ping IPv6, tracert IPv6, socket IPv6, UDP6, and Raw IP6 | |
Multicast | IGMP, PIM-SM, PIM-DM, MSDP, and MBGP |
IGMP snooping | |
IGMP proxy | |
Fast leave of multicast member interfaces | |
Multicast traffic suppression | |
Multicast VLAN | |
MPLS | Basic MPLS functions |
MPLS VPN/VPLS/VPLS over GRE | |
Reliability | Link Aggregation Control Protocol (LACP) |
STP, RSTP, VBST, and MSTP | |
BPDU protection, root protection, and loop protection | |
Smart Link and multi-instance | |
Device Link Detection Protocol (DLDP) | |
Ethernet Ring Protection Switching (ERPS, G.8032) | |
Hardware-based Bi-directional Forwarding Detection (BFD) | |
VRRP, VRRP load balancing, and BFD for VRRP | |
BFD for BGP/IS-IS/OSPF/Static route | |
In-Service Software Upgrade (ISSU) | |
Segment Routing (SR) | |
QoS | Traffic classification based on Layer 2, Layer 3, Layer 4, and priority information |
Actions include ACL, CAR, and re-marking | |
Queue scheduling modes such as PQ, WFQ, and PQ + WRR | |
Congestion avoidance mechanisms, including WRED and tail drop | |
Traffic shaping | |
O&M | IEEE 1588v2 |
Packet Conservation Algorithm for Internet (iPCA) | |
Dynamic Load Balancing (DLB) | |
Dynamic Packet Prioritization (DPP) | |
Network-wide path detection | |
Microsecond-level buffer detection | |
Configuration and Maintenance |
Console, Telnet, and SSH terminals |
Network management protocols, such as SNMPv1/v2c/v3 | |
File upload and download through FTP and TFTP | |
BootROM upgrade and remote upgrade | |
Hot patches | |
User operation logs | |
Zero-Touch Provisioning (ZTP) | |
Security and Management |
802.1x authentication |
RADIUS and HWTACACS authentication for login users | |
Command line authority control based on user levels, preventing unauthorized users from using commands | |
Defense against MAC address attacks, broadcast storms, and heavy-traffic attacks | |
Ping and traceroute | |
Remote Network Monitoring (RMON) | |
Dimensions (W x D x H, mm) |
442 x 813 x 975.1 (22 U) |
Chassis Weight (empty) | < 190 kg (418 lb) |
Operating Voltage | AC: 90V to 290V DC: -38.4V to -72V HVDC: 240V |
Max. Power Supply | 18,000W |
