Description
The Cisco Catalyst 9500‑24Q‑A is a high‑performance, fixed chassis Layer 3 Ethernet switch designed for enterprise campus core, distribution, or data center aggregation deployments. It offers 24×40 Gbps QSFP+ ports with support for breakout to lower speeds (with appropriate optics), delivering ultra‑high bandwidth connectivity and flexible traffic handling. The switch runs Cisco IOS XE with the Network Advantage feature set, enabling advanced routing and segmentation, including BGP, OSPF, EIGRP, MPLS, VXLAN, and more. It also supports high‑availability features such as StackWise Virtual, NSF/SSO, and redundant power supplies and fans for reliable continuous operation.
With 16 GB DRAM and 16 GB flash memory, support for up to 64,000 MAC addresses, 4,000 VLANs, and jumbo frames up to 9,198 bytes, it is suitable for demanding networking environments requiring high throughput and extensive segmentation. Power input supports 90–264 VAC, and the switch operates in typical enterprise temperature and humidity ranges.
Key Features:
24 × 40 GbE QSFP+ ports for high‑density, high‑speed connectivity
Layer 2 and Layer 3 support with Cisco IOS XE networking and advanced routing protocols
Up to 1920 Gbps switching capacity with up to 1440 Mpps forwarding rate
High scalability: up to 64,000 MAC addresses, 4,000 VLAN IDs, and 512,000 flexible NetFlow entries
High availability: StackWise Virtual, redundant power supplies/fans, and Network Advantage features
